Gemco Industrial Brakes

Electro-Thrust Brakes - Electro-Thrust Shoe Brakes (ET Style)

DESCRIPTION

The Electro-Thrust Shoe Brakes have been in service for over 10 years. AISE sizes range from 8 inches in diameter up to 30 inch diameter wheels. Torque values range from 100 foot-pounds to 9,000 ft./lbs.! We also manufacture a line of non-AISE rated brakes. The brakes are spring set for fail-safe operation with an electro-hydraulic actuator that overcomes a setting spring and releases the brake. The actuator is stroked by means of applying power, either AC or DC, to an integral motor attached to a twin cavity housing. The housing is filled with fluid and as the motor spins it creates fluid motion. As the fluid travels through the housing it applies upward pressure to a piston that overcomes the setting spring to release the brake. Cutting power to the motor reverses this function and the spring then gently sets the brake.

The Series ET style of shoe brakes are spring set and electrically released by a continuously rated, sealed electrohydraulic actuator. This brake provides smooth brake setting due to the response of the actuator. This inherent cushion effect is desirable for many brake applications. Rugged construction makes this brake suitable for steel mill cranes, container cranes, stacker reclaimers, lock and dam gates, and other heavy-duty applications.

Documentation Download:
• Industrial Brake Brochure
• Industrial Brake Systems Application Guide
• Electro Thrust (Model ET) Shoe Brakes Manual

CAD Drawings Download:

• ET6NA (PDF)
• ET8 (DXF, ZIP)
• ET8 (PDF)
• ET8NA (PDF)
• ET10 (PDF)
• ET11NA (PDF)
• ET13 (PDF)
• ET13, Certified (PDF)

• ET14NA (PDF)
• ET16 (PDF)
• ET18NA (PDF)
• ET19 (PDF)
• ETH8NA (PDF)
• ETH10 (PDF)
• ETH14NA (PDF)
• ETH14NA, Certified (PDF)

GEMCO ET Electro-Thrust Shoe Brakes

No	Part Number	Description	Image	Stock Qty	Price Each	Update Cart
1	AME-ET-6NA	Ametek Gemco Electro-Thrust Brake Assembly ET-6NA 6 Inch Diameter Brake 60 LB FT Brake Torque, Continuous Rating Adjustable Torque with Scale Indicator 230 / 460 VAC, 3 Phase, 60 Hz. required to release the brake Spring Applied Electrohydraulic Release for Fail Safe Operation -13 thru 104 Degrees F with Standard Thruster Fluid Brake Setting Times Without Adjustable Valve 1.1 Seconds With Adjustable Valve 1.5 to 7.2 Seconds Engineered to apply softly and slowly to avoid swinging loads This brake is not designed for hoist applications Options available at additional cost include: Brake Wheel 6 X 3.125, Finished or Pilot Bore Part E006500 Self Adjusting Mechanism for Lining Wear Limit Switches for Set and Release contacts Silicon Fluid for low temperature applications, -40 Degrees F Brake Hand Release Lever, specify latching or non-latching lever Enclosures NEMA 4 & NEMA 3R & Strip Heater / Thermostat Ships in 6 Weeks Dated 06-2022 Ships via Motor Freight Only 120 LBS Net, 150 LBS Gross	-	1	$5,201.00
2	AME-ET-8	Ametek Gemco Electro-Thrust Brake Assembly Part ET-8 8 Inch Diameter Brake Manufactured to AIST Specifications 100 LB FT Brake Torque, Continuous Rating Adjustable Torque with Scale Indicator 230 / 460 VAC, 3 Phase, 60 Hz. required to release the brake Spring Applied Electrohydraulic Release for Fail Safe Operation -13 thru 104 Degrees F with Standard Thruster Fluid Brake Setting Times Without Adjustable Valve 1.1 Seconds With Adjustable Valve 1.5 to 7.2 Seconds Engineered to apply softly and slowly to avoid swinging loads This brake is not designed for hoist applications Options available at additional cost include: Brake Wheel 8 X 3.25 Inch, Finished or Pilot Bore Part E008500 Self Adjusting Mechanism for Lining Wear Limit Switches for Set and Release contacts Silicon Fluid for low temperature applications, -40 Degrees F Brake Hand Release Lever, specify latching or non-latching lever Enclosures NEMA 4 & NEMA 3R & Strip Heater / Thermostat Ships from Stock to 5 Weeks Motor Freight Only 140 LBS Net, 170 LBS Gross Dated 1-2020	-	1	$5,282.28
3	AME-ET-8DC	Ametek Gemco Electro-Thrust Brake Assembly Part ET-8DC Manufactured to AIST Specifications 8 Inch Diameter Brake 100 LB FT Brake Torque, Continuous Rating Adjustable Torque with Scale Indicator 230 Volt DC, Shunt Wound Only, required to release the brake Spring Applied Electrohydraulic Release for Fail Safe Operation -13 thru 104 Degrees F with Standard Thruster Fluid Brake Setting Times Without Adjustable Valve 1.1 Seconds With Adjustable Valve 1.5 to 7.2 Seconds Engineered to apply softly and slowly to avoid swinging loads This brake is not designed for hoist applications Options available at additional cost include: Brake Wheel 8 X 3.25 Inch, Finished or Pilot Bore Part E008500 Self Adjusting Mechanism for Lining Wear Limit Switches for Set and Release contacts Silicon Fluid for low temperature applications, -40 Degrees F Brake Hand Release Lever, specify latching or non-latching lever Enclosures NEMA 4 & NEMA 3R & Strip Heater / Thermostat 140 LBS Net, 170 LBS Gross Ships via Motor Freight Only Dated 1/18	-	0	$7,850.52
4	AME-ET-8NA	Ametek Gemco Electro-Thrust Brake Assembly Part ET-8NA 8 Inch Diameter Brake 160 LB FT Brake Torque, Continuous Rating Adjustable Torque with Scale Indicator 230 / 460 VAC, 3 Phase, 60 Hz. required to release the brake Spring Applied Electrohydraulic Release for Fail Safe Operation -13 thru 104 Degrees F with Standard Thruster Fluid Brake Setting Times Without Adjustable Valve 1.1 Seconds With Adjustable Valve 1.5 to 7.2 Seconds Engineered to apply softly and slowly to avoid swinging loads This brake is not designed for hoist applications Options available at additional cost include: Brake Wheel 8 X 3.25 Inch, Finished or Pilot Bore Part E008500 Self Adjusting Mechanism for Lining Wear Limit Switches for Set and Release contacts Silicon Fluid for low temperature applications, -40 Degrees F Brake Hand Release Lever, specify latching or non-latching lever Enclosures NEMA 4 & NEMA 3R & Strip Heater / Thermostat Ships via Motor Freight Only 140 LBS Net, 170 LBS Gross Ship in 6 to 8 Weeks, Peck MI Dated 06-2022	-	3	$5,660.00
5	AME-ET-10	Ametek Gemco Electro-Thrust Brake Assembly ET-10 10 Inch Diameter Brake Manufactured to AIST Specifications 200 LB FT Brake Torque, Continuous Rating Adjustable Torque with Scale Indicator 230 / 460 VAC, 3 Phase, 60 Hz. required to release the brake Spring Applied Electrohydraulic Release for Fail Safe Operation -13 thru 104 Degrees F with Standard Thruster Fluid Brake Setting Times Without Adjustable Valve 0.75 Seconds With Adjustable Valve 1.3 to 7.3 Seconds Engineered to apply softly and slowly to avoid swinging loads This brake is not designed for hoist applications Options available at additional cost include: Brake Wheel 10 X 3.75 Inch, Finished or Pilot Bore Part E010500 Self Adjusting Mechanism for Lining Wear Limit Switches for Set and Release contacts Silicon Fluid for low temperature applications, -40 Degrees F Brake Hand Release Lever, specify latching or non-latching lever Enclosures NEMA 4 & NEMA 3R & Strip Heater / Thermostat Ships via Motor Freight Only 150 LBS Net, 180 LBS Gross Ships in 8 to 10 Weeks Dated 01-2023	-	0	$7,383.00
6	AME-ET-11NA	Ametek Gemco Electro-Thrust Brake Assembly 11" Part ET-11NA 11 Inch Diameter Brake 400 LB FT Brake Torque, Continuous Rating Adjustable Torque with Scale Indicator 230 / 460 VAC, 3 Phase, 60 Hz. required to release the brake Spring Applied Electrohydraulic Release for Fail Safe Operation -13 thru 104 Degrees F with Standard Thruster Fluid Brake Setting Times Without Adjustable Valve 0.75 Seconds With Adjustable Valve 1.3 to 7.3 Seconds Engineered to apply softly and slowly to avoid swinging loads This brake is not designed for hoist applications Options available at additional cost include: Brake Wheel 11 X 5.00 Inch, Finished or Pilot Bore Part E011500 Self Adjusting Mechanism for Lining Wear Limit Switches for Set and Release contacts Silicon Fluid for low temperature applications, -40 Degrees F Brake Hand Release Lever, specify latching or non-latching lever Enclosures NEMA 4 & NEMA 3R & Strip Heater / Thermostat Ships via Motor Freight Only Ships in 8 to 10 Weeks, Peck MI Dated 01-2023 170 LBS Net, 200 LBS Gross	-	0	$8,725.00
7	AME-ET-13	Ametek Gemco Electro-Thrust Brake Assembly ET-13 13 Inch Diameter Brake Manufactured to AIST Specifications 550 LB FT Brake Torque, Continuous Rating Adjustable Torque with Scale Indicator 230 / 460 VAC, 3 Phase, 60 Hz. required to release the brake Spring Applied Electrohydraulic Release for Fail Safe Operation -13 thru 104 Degrees F with Standard Thruster Fluid Brake Setting Times Without Adjustable Valve 0.75 Seconds With Adjustable Valve 1.2 to 4.8 Seconds Engineered to apply softly and slowly to avoid swinging loads This brake is not designed for hoist applications Options available at additional cost include: Brake Wheel 13 X 5.75 Inch, Finished or Pilot Bore Part E013500 Self Adjusting Mechanism for Lining Wear Limit Switches for Set and Release contacts Silicon Fluid for low temperature applications, -40 Degrees F Brake Hand Release Lever, specify latching or non-latching lever Enclosures NEMA 4 & NEMA 3R & Strip Heater / Thermostat 250 LBS Net, 280 LBS Gross Ships via Motor Freight Only Ships in 10 Weeks, Peck MI Dated 06-2022	-	0	$9,273.00
8	AME-ET-13DC	Ametek Gemco Electro-Thrust Brake Assembly ET-13 13 Inch Diameter Brake Manufactured to AIST Specifications 550 LB FT Brake Torque, Continuous Rating Adjustable Torque with Scale Indicator 230 Volt DC, Shunt Wound Only, required to release the brake Spring Applied Electrohydraulic Release for Fail Safe Operation -13 thru 104 Degrees F with Standard Thruster Fluid Brake Setting Times Without Adjustable Valve 0.75 Seconds With Adjustable Valve 1.2 to 4.8 Seconds Engineered to apply softly and slowly to avoid swinging loads This brake is not designed for hoist applications Options available at additional cost include: Brake Wheel 13 X 5.75 Inch, Finished or Pilot Bore Part E013500 Self Adjusting Mechanism for Lining Wear Limit Switches for Set and Release contacts Silicon Fluid for low temperature applications, -40 Degrees F Brake Hand Release Lever, specify latching or non-latching lever Enclosures NEMA 4 & NEMA 3R & Strip Heater / Thermostat 250 LBS Net, 280 LBS Gross Ships via Motor Freight Only	-	0	$10,053.71
9	AME-ET-14NA	Ametek Gemco Electro-Thrust Brake Assembly Part ET-14NA 14 Inch Diameter Brake 800 LB FT Brake Torque, Continuous Rating Adjustable Torque with Scale Indicator 230 / 460 VAC, 3 Phase, 60 Hz. required to release the brake Spring Applied Electrohydraulic Release for Fail Safe Operation -13 thru 104 Degrees F with Standard Thruster Fluid Brake Setting Times Without Adjustable Valve 0.75 Seconds With Adjustable Valve 1.2 to 4.8 Seconds Engineered to apply softly and slowly to avoid swinging loads This brake is not designed for hoist applications Options available at additional cost include: Brake Wheel 14 X 4.25 Inch, Finished or Pilot Bore Part E014500 Self Adjusting Mechanism for Lining Wear Limit Switches for Set and Release contacts Silicon Fluid for low temperature applications, -40 Degrees F Brake Hand Release Lever, specify latching or non-latching lever Enclosures NEMA 4 & NEMA 3R & Strip Heater / Thermostat 360 LBS Net, 410 LBS Gross Ships via Motor Freight Only Ships in 6 Weeks Dated 06-2022	-	0	$11,797.00
10	AME-ET-14NA DC	Ametek Gemco Electro-Thrust Brake Assembly ET-14NADC 14 Inch Diameter Brake 800 LB FT Brake Torque, Continuous Rating Adjustable Torque with Scale Indicator 230 Volt DC, Shunt Wound Only, required to release the brake Spring Applied Electrohydraulic Release for Fail Safe Operation -13 thru 104 Degrees F with Standard Thruster Fluid Brake Setting Times Without Adjustable Valve 0.75 Seconds With Adjustable Valve 1.2 to 4.8 Seconds Engineered to apply softly and slowly to avoid swinging loads This brake is not designed for hoist applications Options available at additional cost include: Brake Wheel 14 X 4.25 Inch, Finished or Pilot Bore Part E014500 Self Adjusting Mechanism for Lining Wear Limit Switches for Set and Release contacts Silicon Fluid for low temperature applications, -40 Degrees F Brake Hand Release Lever, specify latching or non-latching lever Enclosures NEMA 4 & NEMA 3R & Strip Heater / Thermostat 320 LBS Net, 370 LBS Gross Ships via Motor Freight Only	-	0	$12,007.42
11	AME-ET-16	Ametek Gemco Electro-Thrust Brake Assembly ET-16 16 Inch Diameter Brake Manufactured to AIST Specifications 1000 LB FT Brake Torque, Continuous Rating Adjustable Torque with Scale Indicator 230 / 460 VAC, 3 Phase, 60 Hz. required to release the brake Spring Applied Electrohydraulic Release for Fail Safe Operation -13 thru 104 Degrees F with Standard Thruster Fluid Brake Setting Times Without Adjustable Valve 0.45 Seconds With Adjustable Valve 0.8 to 3.8 Seconds Engineered to apply softly and slowly to avoid swinging loads This brake is not designed for hoist applications Options available at additional cost include: Brake Wheel 16 X 6.75 Inch, Finished or Pilot Bore Part E016500 Self Adjusting Mechanism for Lining Wear Limit Switches for Set and Release contacts Silicon Fluid for low temperature applications, -40 Degrees F Brake Hand Release Lever, specify latching or non-latching lever Enclosures NEMA 4 & NEMA 3R & Strip Heater / Thermostat 400 LBS Net, 430 LBS Gross Ships via Motor Freight Only Ships in 6 Weeks, Peck MI Dated 01-2021	-	0	$12,243.96
12	AME-ET-16DC	Ametek Gemco Electro-Thrust Brake Assembly ET-16 16 Inch Diameter Brake Manufactured to AIST Specifications 1000 LB FT Brake Torque, Continuous Rating Adjustable Torque with Scale Indicator 230 Volt DC, Shunt Wound Only, required to release the brake Spring Applied Electrohydraulic Release for Fail Safe Operation -13 thru 104 Degrees F with Standard Thruster Fluid Brake Setting Times Without Adjustable Valve 0.45 Seconds With Adjustable Valve 0.8 to 3.8 Seconds Engineered to apply softly and slowly to avoid swinging loads This brake is not designed for hoist applications Options available at additional cost include: Brake Wheel 16 X 6.75 Inch, Finished or Pilot Bore Part E016500 Self Adjusting Mechanism for Lining Wear Limit Switches for Set and Release contacts Silicon Fluid for low temperature applications, -40 Degrees F Brake Hand Release Lever, specify latching or non-latching lever Enclosures NEMA 4 & NEMA 3R & Strip Heater / Thermostat 400 LBS Net, 430 LBS Gross Ships via Motor Freight Only	-	0	$12,736.42
13	AME-ET-18NA	Ametek Gemco Electro-Thrust Brake Assembly ET-18NA 18 Inch Diameter Brake 1500 LB FT Brake Torque, Continuous Rating Adjustable Torque with Scale Indicator 230 / 460 VAC, 3 Phase, 60 Hz. required to release the brake Spring Applied Electrohydraulic Release for Fail Safe Operation -13 thru 104 Degrees F with Standard Thruster Fluid Brake Setting Times Without Adjustable Valve 0.35 Seconds With Adjustable Valve 0.7 to 3.0 Seconds Engineered to apply softly and slowly to avoid swinging loads This brake is not designed for hoist applications Options available at additional cost include: Brake Wheel 18 X 8.50 Inch, Finished or Pilot Bore Part BH181001 Self Adjusting Mechanism for Lining Wear Limit Switches for Set and Release contacts Silicon Fluid for low temperature applications, -40 Degrees F Brake Hand Release Lever, specify latching or non-latching lever Enclosures NEMA 4 & NEMA 3R & Strip Heater / Thermostat 580 LBS Net, 610 LBS Gross Ships via Motor Freight Only Dated 06-2022	-	0	$15,949.00
14	AME-ET-18NA DC	Ametek Gemco Electro-Thrust Brake Assembly ET-18NADC 18 Inch Diameter Brake 1500 LB FT Brake Torque, Continuous Rating Adjustable Torque with Scale Indicator 230 Volt DC, Shunt Wound Only, required to release the brake Spring Applied Electrohydraulic Release for Fail Safe Operation -13 thru 104 Degrees F with Standard Thruster Fluid Brake Setting Times Without Adjustable Valve 0.35 Seconds With Adjustable Valve 0.7 to 3.0 Seconds Engineered to apply softly and slowly to avoid swinging loads This brake is not designed for hoist applications Options available at additional cost include: Brake Wheel 18 X 8.50 Inch, Finished or Pilot Bore Part BH181001 Self Adjusting Mechanism for Lining Wear Limit Switches for Set and Release contacts Silicon Fluid for low temperature applications, -40 Degrees F Brake Hand Release Lever, specify latching or non-latching lever Enclosures NEMA 4 & NEMA 3R & Strip Heater / Thermostat 580 LBS Net, 610 LBS Gross Ships via Motor Freight Only	-	0	$15,221.50
15	AME-ET-19	Ametek Gemco Electro-Thrust Brake Assembly ET-19 19 Inch Diameter Brake Manufactured to AIST Specifications 2000 LB FT Brake Torque, Continuous Rating Adjustable Torque with Scale Indicator 230 / 460 VAC, 3 Phase, 60 Hz. required to release the brake Spring Applied Electrohydraulic Release for Fail Safe Operation -13 thru 104 Degrees F with Standard Thruster Fluid Brake Setting Times Without Adjustable Valve 0.35 Seconds With Adjustable Valve 0.7 to 3.0 Seconds Engineered to apply softly and slowly to avoid swinging loads This brake is not designed for hoist applications Options available at additional cost include: Brake Wheel 19 X 8.75 Inch, Finished or Pilot Bore Part E019500 Self Adjusting Mechanism for Lining Wear Limit Switches for Set and Release contacts Silicon Fluid for low temperature applications, -40 Degrees F Brake Hand Release Lever, specify latching or non-latching lever Enclosures NEMA 4 & NEMA 3R & Strip Heater / Thermostat 640 LBS Net, 670 LBS Gross Ships via Motor Freight Only	-	0	$15,275.52
16	AME-ET-19NA	Ametek Gemco Electro-Thrust Brake Assembly ET-19NA 19 Inch Diameter Brake 1600 LB FT Brake Torque, Continuous Rating Adjustable Torque with Scale Indicator 230 Volt DC is required to release the brake Spring Applied Electrohydraulic Release for Fail Safe Operation -13 thru 104 Degrees F with Standard Thruster Fluid Brake Setting Times Without Adjustable Valve 0.35 Seconds With Adjustable Valve 0.7 to 3.0 Seconds Engineered to apply softly and slowly to avoid swinging loads This brake is not designed for hoist applications Options available at additional cost include: Brake Wheel 19 X 8.75 Inch, Finished or Pilot Bore Part E019500 Self Adjusting Mechanism for Lining Wear Limit Switches for Set and Release contacts Silicon Fluid for low temperature applications, -40 Degrees F Brake Hand Release Lever, specify latching or non-latching lever Enclosures NEMA 4 & NEMA 3R & Strip Heater / Thermostat 640 LBS Net, 670 LBS Gross Ships via Motor Freight Only Pricing on request	-	0	Call	Call

GEMCO ETH Electro-Thrust Shoe Brakes

No	Part Number	Description	Image	Price Each
1	AME-ETH-08 BRAKE ONLY	Ametek Gemco Electro-Thrust Brake Assembly, 8 Inch Diameter Brake, 100 LB FT, 230 / 460 VAC, 3 Phase, 60 Hz., Built to AISE Specifications, Spring Applied Electrohydraulic Release or Electrohydraulically Released and Control Cylinder / Hydraulically Applied via an existing hydraluc brake system, -13 thru 104 Degrees F. Brake Setting Times, Without Adjusting Valve 1.10 Seconds. With Adjusting Valve 1.5 to 7.2 Seconds to softly apply the brake. Engineered for Overhead Crane Trolley & Bridge Applications to reduce swinging loads. NOT designed for hoisting applications. 140 LBS + skid. Options available at additional cost include: Self Adjusting Mechanism for Lining Wear, Limit Switches for set and release information, Silicon Fluid for low temperature application -40 degrees F., Hand Release (latching or non-latching) enclosures, strip heaters	-	$7,159.31
2	AME-ETH-08NA-DC BRAKE ONLY	Ametek Gemco Electro-Thrust Brake Assembly, 8 Inch Diameter Brake with hydraulic slave actuator for auxiliary manual cab control via a existing Wagner hydraulic brake system., 160 LB FT, 230 Volt DC Motor, Built to AISE Specifications with the exception of the brake torque which is 60 FT LB higher than AISE specifies, Spring Applied Electrohydraulic Release, -13 thru 104 Degrees F. Brake Setting Times; Without Adjusting Valve 1.1 Sec. With Adjusting Valve 1.5 to 7.2 Sec. to softly apply the brake. Engineered for Overhead Crane Trolley & Bridge Applications to reduce swinging loads. NOT designed for hoist application (165LBS) Options available at additional cost include: Limit Switches for set and release information, Silicon Fluid for low temperature application -40 degrees F., Hand Release (latching or non-latching) enclosures and strip heaters	-	$9,404.63
3	AME-ETH-08NA-DC SYSTEM	Options available at additional cost include: Limit Switches for set and release information, Silicon Fluid for low temperature application -40 degrees F., Hand Release (latching or non-latching) enclosures and strip heaters	-	$14,860.78
4	AME-ETH-08NA BRAKE ONLY	Ametek Gemco Electro-Thrust Brake Assembly, 8 Inch Diameter Brake, 160 LB FT, 230 / 460 VAC, 3 Phase, 60 Hz., Built to AISE Specifications, Spring Applied Electrohydraulic Release or Electrohydraulically Released and Control Cylinder / Hydraulically Applied via an existing hydraluc brake system, -13 thru 104 Degrees F. Brake Setting Times, Without Adjusting Valve 1.10 Seconds. With Adjusting Valve 1.5 to 7.2 Seconds to softly apply the brake. Engineered for Overhead Crane Trolley & Bridge Applications to reduce swinging loads. NOT designed for hoisting applications. 140 LBS + skid. Options available at additional cost include: Self Adjusting Mechanism for Lining Wear, Limit Switches for set and release information, Silicon Fluid for low temperature application -40 degrees F., Hand Release (latching or non-latching) enclosures, strip heaters	-	$7,159.31
5	AME-ETH-10-DC BRAKE ONLY	Ametek Gemco Electro-Thrust Brake Assembly, 10 Inch Diameter Brake with hydraulic slave actuator for auxiliary manual cab control via a existing Wagner hydraulic brake system., 200 LB FT, 230 Volt DC Motor, Built to AISE Specifications, Spring Applied Electrohydraulic Release, -13 thru 104 Degrees F. Brake Setting Times; Without Adjusting Valve 0.75 Sec. With Adjusting Valve 1.3 to 7.3 Sec. to softly apply the brake. Engineered for Overhead Crane Trolley & Bridge Applications to reduce swinging loads. NOT designed for hoist application. Options available at additional cost include: Limit Switches for set and release information, Silicon Fluid for low temperature application -40 degrees F., Hand Release (latching or non-latching) enclosures and strip heaters # 82300014 (165LBS)	-	$10,475.99
6	AME-ETH-10 1 BRKSYS AC	Ametek Gemco Electro-Thrust Brake Assembly, 10 Inch Diameter Brake with hydraulic slave actuator for auxiliary manual cab control via a foot pedal. 200 Ft LB, 230 / 460 VAC, 3 Phase, 60 Hz., Built to AISE Specifications, Spring Applied Electrohydraulic Release or Electrohydraulically Released and Control Cylinder / Hydraulically Applied, -13 thru 104 Degrees F. Brake Setting Times, Without Adjusting Valve 0.75 Sec. With Adjusting Valve 1.3 to 7.3 Sec. to softly apply the brake, Engineered for Overhead Crane Trolley & Bridge Applications to reduce swinging loads. NOT designed for hoisting applications. System includes: Qty. 1, ETH-10 Brake Assembly, Fluid Reservoir Bleeder, Pushbutton Switch with Enclosure for operating the bleeder check valve, Control Cylinder with Foot Pedal, 100 Feet of Hydraulic Tubing, Tube Fittings, Unions, Clamps, Bushings, Brackets, Gaskets, 4 Armored Flexible Hoses & Wagner 21B DOT 3 Super Heavy Duty Brake Fluid SAE1703400 LBS + skid. Options available at additional cost include: Limit Switches for set and release information, Silicon Fluid for low temperature application -40 degrees F., Hand Release (latching or non-latching) enclosures and strip heaters	-	$13,197.58
7	AME-ETH-10 2 BRKSYS DC	Ametek Gemco Electro-Thrust Brake System with Hydraulic Cab Control. 10 Inch Diameter Brake, 200 LB FT, 230 VDC Shunt Wound Motor. Built to AISE Specifications, Spring Applied Electrohydraulic Release, -13 thru 104 Degrees F. Brake Setting Times, Without Adjusting Valve 0.75 Sec. With Adjusting Valve 1.3 to 7.3 Sec. to softly apply the brake, hydraulic actuator for auxiliary cab control for a progressive hydraulic brake pedal actuation. System includes: Qty. 1, ET-10 Brake Assembly, Fluid Reservoir Bleeder, Pushbutton Switch with Enclosure for operating the bleeder check valve, Control Cylinder with Foot Pedal, 100 Feet of Hydraulic Tubing, Tube Fittings, Unions, Clamps, Bushings, Brackets, Gaskets, 4 Armored Flexible Hoses & Wagner 21B DOT 3 Super Heavy Duty Brake Fluid SAE1703	-	$26,809.88
8	AME-ETH-10 BRAKE ONLY	Ametek Gemco Electro-Thrust Brake Assembly, 10 Inch Diameter Brake, 200 LB FT, 230 / 460 VAC, 3 Phase, 60 Hz., Built to AISE Specifications, Spring Applied Electrohydraulic Release or Electrohydraulically Released and Control Cylinder / Hydraulically Applied via an existing hydraluc brake system, -13 thru 104 Degrees F. Brake Setting Times, Without Adjusting Valve 0.75 Sec. With Adjusting Valve 1.3 to 7.3 Sec. to softly apply the brake. Engineered for Overhead Crane Trolley & Bridge Applications to reduce swinging loads. NOT designed for hoisting applications. 150 LBS + skid. Options available at additional cost include: Self Adjusting Mechanism for Lining Wear, Limit Switches for set and release information, Silicon Fluid for low temperature application -40 degrees F., Hand Release (latching or non-latching) enclosures, strip heaters	-	$11,695.00
9	AME-ETH-10 BRAKE SYS DC	Ametek Gemco Electro-Thrust Brake System with Hydraulic Cab Control. 10 Inch Diameter Brake, 200 LB FT, 230 VDC Shunt Wound Motor. Built to AISE Specifications, Spring Applied Electrohydraulic Release, -13 thru 104 Degrees F. Brake Setting Times, Without Adjusting Valve 0.75 Sec. With Adjusting Valve 1.3 to 7.3 Sec. to softly apply the brake, hydraulic actuator for auxiliary cab control for a progressive hydraulic brake pedal actuation. System includes: Qty. 1, ET-10 Brake Assembly, Fluid Reservoir Bleeder, Pushbutton Switch with Enclosure for operating the bleeder check valve, Control Cylinder with Foot Pedal, 100 Feet of Hydraulic Tubing, Tube Fittings, Unions, Clamps, Bushings, Brackets, Gaskets, 4 Armored Flexible Hoses & Wagner 21B DOT 3 Super Heavy Duty Brake Fluid SAE1703	-	$15,853.30
10	AME-ETH-11 BRAKE ONLY	400 FT LBS Dated 1/18	-	$10,378.80
11	AME-ETH-13 BRAKE ONLY	Ametek Gemco Electro-Thrust Brake Assembly, 13 Inch Diameter Brake with hydraulic slave actuator for auxiliary manual cab control via a existing Wagner hydraulic brake system., 550 LB FT, 230 / 460 VAC, 3 Phase, 60 Hz., Built to AISE Specifications, Spring Applied Electrohydraulic Release, -13 thru 104 Degrees F. Brake Setting Times, Without Adjusting Valve 0.75 Sec. With Adjusting Valve 1.2 to 4.8 Sec. to softly apply the brake, Engineered for Overhead Crane Trolley & Bridge Applications to reduce swinging loads. NOT designed for hoist application. 250 LBS + skid. Options available at additional cost include: Limit Switches for set and release information, Silicon Fluid for low temperature application -40 degrees F., Hand Release (latching or non-latching) enclosures and strip heaters	-	$9,795.59
12	AME-ETH-13 BRAKE ONLY DC	Ametek Gemco spring applied, electro-hydraulically released, 13 inch brake assembly with hydraulic slave actuator for auxiliary manual cab control via the existing Wagner hydraulic brake system. The hydraulic thruster is powered by a 230 Volt DC Shunt Wound Motor.550 FT LBS.	-	$12,451.30
13	AME-ETH-13 BRAKE SYS	Ametek Gemco Electro-Thrust Brake Assembly, 13 Inch Diameter Brake with hydraulic slave actuator for auxiliary manual cab control via a existing Wagner hydraulic brake system., 550 LB FT, 230 / 460 VAC, 3 Phase, 60 Hz., Built to AISE Specifications, Spring Applied Electrohydraulic Release, -13 thru 104 Degrees F. Brake Setting Times, Without Adjusting Valve 0.75 Sec. With Adjusting Valve 1.2 to 4.8 Sec. to softly apply the brake, Engineered for Overhead Crane Trolley & Bridge Applications to reduce swinging loads. NOT designed for hoist application. 250 LBS + skid. Options available at additional cost include: Limit Switches for set and release information, Silicon Fluid for low temperature application -40 degrees F., Hand Release (latching or non-latching) enclosures and strip heaters. System includes: Qty. 1, ET-13H Brake Assembly, Fluid Reservoir Bleeder, Pushbutton Switch with Enclosure for operating the bleeder check valve, Control Cylinder with Foot Pedal, 100 Feet of Hydraulic Tubing, Tube Fittings, Unions, Clamps, Bushings, Brackets, Gaskets, 4 Armored Flexible Hoses & Wagner 21B DOT 3 Super Heavy Duty Brake Fluid SAE1703	-	$14,897.50
14	AME-ETH-13 BRAKE SYS DC	Ametek Gemco Electro-Thrust Brake System with Hydraulic Cab Control. 13 Inch Diameter Brake, 550 LB FT, 230 VDC Shunt Wound Motor. Built to AISE Specifications, Spring Applied Electrohydraulic Release, -13 thru 104 Degrees F. Brake Setting Times, Without Adjusting Valve 0.75 Sec. With Adjusting Valve 1.2 to 4.8 Sec. to softly apply the brake, hydraulic actuator for auxiliary cab control for a progressive hydraulic brake pedal actuation. System includes: Qty. 1, ET-13 Brake Assembly, Fluid Reservoir Bleeder, Pushbutton Switch with Enclosure for operating the bleeder check valve, Control Cylinder with Foot Pedal, 100 Feet of Hydraulic Tubing, Tube Fittings, Unions, Clamps, Bushings, Brackets, Gaskets, 4 Armored Flexible Hoses & Wagner 21B DOT 3 Super Heavy Duty Brake Fluid SAE1703	-	$17,553.22
15	AME-ETH-14NA	Ametek Gemco spring applied, electro-hydraulically released brake assembly with hydraulic actuator for auxiliary manual cab control via foot pedal (sold separately). The thruster includes a 230VDC motor. The brake is set up for a 14" diameter wheel which is not included. Two 10797 armored hose kits are included. A fluid reservoir bleeder is required, but not included. A manual hydraulic foot pedal control cylinder is required, but not included	-	$11,793.58
16	AME-ETH-14NA-DC BRAKE ONLY	Ametek Gemco Electro-Thrust Brake Assembly, 14 Inch Diameter Brake with hydraulic slave actuator for auxiliary manual cab control via a existing Wagner hydraulic brake system., 800 LB FT, 230 Volt DC Motor, Spring Applied Electrohydraulic Release, -13 thru 104 Degrees F. Brake Setting Times; Without Adjusting Valve 0.45 Sec. With Adjusting Valve 1.2 to 4.8 Sec. to softly apply the brake. Engineered for Overhead Crane Trolley & Bridge Applications to reduce swinging loads. NOT designed for hoist application. Options available at additional cost include: Limit Switches for set and release information, Silicon Fluid for low temperature application -40 degrees F., Hand Release (latching or non-latching) enclosures and strip heaters # (300LBS)	-	$14,449.30
17	AME-ETH-14NA BO	Ametek Gemco spring applied, electro-hydraulically released, 14 inch brake assembly with hydraulic slave actuator for auxiliary manual cab control via the existing Wagner hydraulic brake system. The hydraulic thruster is powered by a 460 / 230 Volt AC motor. 800 FT LBS.	-	$11,803.30
18	AME-ETH-16 BRAKE ONLY	Ametek Gemco Electro-Thrust Brake Assembly, 16 Inch Diameter Brake with hydraulic slave actuator for auxiliary manual cab control via a existing Wagner hydraulic brake system., 1000 LB FT, 230 / 460 VAC, 3 Phase, 60 Hz., Built to AISE Specifications, Spring Applied Electrohydraulic Release, -13 thru 104 Degrees F. Brake Setting Times, Without Adjusting Valve 0.45 Sec. With Adjusting Valve 0.8 to 3.8 Sec. to softly apply the brake, Engineered for Overhead Crane Trolley & Bridge Applications to reduce swinging loads. NOT designed for hoist application. 400 LBS + skid. Options available at additional cost include: Limit Switches for set and release information, Silicon Fluid for low temperature application -40 degrees F., Hand Release (latching or non-latching) enclosures and strip heaters 01/11	-	$10,907.98
19	AME-ETH-16 BRAKE ONLY DC	Ametek Gemco spring applied, electro-hydraulically released brake assembly with hydraulic actuator for auxiliary manual cab control via foot pedal (sold separately). 1000 LB / FT. Brake Setting Times, Without Adjusting Valve 0.45 Sec. With Adjusting Valve 0.8 to 3.8 Sec. to softly apply the brake.The thruster includes a 230VDC motor. The brake is set up for a 16" diameter wheel which is not included. A fluid reservoir bleeder is required, but not included. A manual hydraulic foot pedal control cylinder is required, but not included.	-	$13,092.82
20	AME-ETH-16 BRAKE SYS DC	Ametek Gemco spring applied, electro-hydraulically released brake system with hydraulic actuator for auxiliary manual cab control via foot pedal. 1000 LB / FT. Brake Setting Times, Without Adjusting Valve 0.45 Sec. With Adjusting Valve 0.8 to 3.8 Sec. to softly apply the brake. The thruster includes a 230VDC Shunt Wound Motor. The brake is set up for a 16" diameter wheel which is not included. System includes: Qty. 1, ETH-16 Brake Assembly, Fluid Reservoir Bleeder, Pushbutton Switch with Enclosure for operating the bleeder check valve, Control Cylinder with Foot Pedal, 100 Feet of Hydraulic Tubing, Tube Fittings, Unions, Clamps, Bushings, Brackets, Gaskets, 4 Armored Flexible Hoses & Wagner 21B DOT 3 Super Heavy Duty Brake Fluid SAE1703	-	$19,987.53
21	AME-ETH-16 BRAKE SYSTEM AC	Ametek Gemco Electro-Thrust Brake Assembly, 16 Inch Diameter Brake with hydraulic slave actuator for auxiliary manual cab control via a foot pedal. 1000 LB FT, 230 / 460 VAC, 3 Phase, 60 Hz., Built to AISE Specifications, Spring Applied Electrohydraulic Release, -13 thru 104 Degrees F. Brake Setting Times, Without Adjusting Valve 0.45 Sec. With Adjusting Valve 0.8 to 3.8 Sec. to softly apply the brake, Engineered for Overhead Crane Trolley & Bridge Applications to reduce swinging loads. NOT designed for hoist application. System includes: Qty. 1, ETH-16 Brake Assembly, Fluid Reservoir Bleeder, Pushbutton Switch with Enclosure for operating the bleeder check valve, Control Cylinder with Foot Pedal, 100 Feet of Hydraulic Tubing, Tube Fittings, Unions, Clamps, Bushings, Brackets, Gaskets, 4 Armored Flexible Hoses & Wagner 21B DOT 3 Super Heavy Duty Brake Fluid SAE1703400 LBS + skid. Options available at additional cost include: Limit Switches for set and release information, Silicon Fluid for low temperature application -40 degrees F., Hand Release (latching or non-latching) enclosures and strip heaters	-	$17,835.10

GEMCO ET/ETH Brakes Brake Shoes, Linings, Bolts and Pins

No	Part Number	Description	Image	Stock Qty	Price Each	Update Cart
1	AME-E004047	Ametek Gemco Brake Shoe Assembly TM-43 Part E004047 aka 645C555G02 E004047002 Brake Shoe & Lining For a TM-43 4.5 Inch Electric Brake Bonded Premium Non-Asbestos Lining Material 2 Per brake, sold each 70 Degree Arc Dated 01-2024 (2LBS) H 4" L 5" W 4" Box	-	4	$749.00
2	AME-E004070	Ametek Gemco Bolt Part E004070 Hardened Brake Shoe Bolt For a TM-43 or TM-63 DC Brake aka 27D7221H04 E004070006 Item 15, 2 per brake, sold each Dated 01-2024 (1LB)	-	0	$237.00
3	AME-E006023	Ametek Gemco Brake Shoe Assembly TM 6" Part E006023 aka E006023002 For 6 Inch a TM-63, ET6 or ET6NA Brake Bonded Premium Non-Asbestos Lining Material Sold each, 2 per Brake 70 Degree Arc Old Part 645C162G02 & 645C162J04 Casting # Normally a Stock Item @ BPI Ships from Stock to 4 weeks Dated 01-2024 (2LBS) H 4" L 10" W 4" Box		0	$806.00
4	AME-E008025	Ametek Gemco Brake Shoe Assembly TM 8" Part E008025 aka E008025002 Brake Shoe & Lining Assembly For an 8 Inch TM-83 or ET-8 Brake Item 14, 2 per brake, sold each Premium Bonded, Non-Asbestos Material Old WEST 439C314G02 Normally a Stock Item @ BPI Ships from Stock to 3 Weeks Dated 01-2024 (3LBS) H 4" L 8" W 4" Box		0	$880.00
5	AME-E010047	Ametek Gemco Brake Shoe Assembly TM 10" Part E010047 aka E0100470002 Old Part 635C292G01 For a 10 Inch TM-1035 or ET-10 Brake Item 14 2 per brake, sold each Premium OEM Non-Asbestos Bonded Lining Material Normally a Stock Item @ BPI Ships from Stock to 3 Weeks Dated 01-2024 (5LBS) H 4" L 10" W 4" Box		0	$1,060.00
6	AME-E010107	Ametek Gemco Shoe & Lining CB 10" Part E010107 aka E010107006 Old Part 254C27G04 Outer Brake Shoe For a CB-160 10 Inch Electric Brake Bonded Premium Non-Asbestos Lining Material Normally a Stock Item @ BPI Ships from Stock to 3 Weeks Dated 01-2025 (15LBS)		0	$1,988.00
7	AME-E010108	Ametek Gemco Lining & Rivet Kit CB160 Part E010108 aka E010108005 Old Part 3279B95G04 For a 10 Inch CB-160 Solenoid Brake Premium OEM Non-Asbestos Drilled Linings Qty. 2, with 6 Drilled and Countersunk Holes & 18 Brass Push Pins Linings for 2 Brake Shoes - 1 Pair Normally a Stock Item at BPI Ships from our Stock to 2 Weeks C. F. for Pricing Dated 01-2024 (2LBS) H 4" L 8" W 4" Box	-	5	$2,529.80
8	AME-E013025	Ametek Gemco Brake Shoe & Lining TM13 Part E013025 aka E013025002 Old Part 439C201G01 For a 13 Inch TM1355 or ET13 Brake Item 14, 2 per brake, sold each Bonded, Premium Non-Asbestos Lining Material Normally a Stock item @ BPI Ships from Stock to 3 Weeks Dated 01-2024 (12LBS) H 8" L 12" W 8" Box	-	0	$1,275.00
9	AME-E013053	Ametek Gemco Bolt TM1355 Part E013053 aka E013053006 Old Part 24D6387G04 Hardened Brake Shoe Bolt Assembly For 13 Inch TM-1355 DC Brake Item 16, 2 per brake, sold each Normally a Stock Item @ BPI Ships from Stock to 3 Weeks Dated 01-2024 (5LBS)	-	0	$367.00
10	AME-E016025	Ametek Gemco Brake Shoe Assembly TM 16" Part E016025 aka E016025002 Old Part 635C227G01 For a 16 Inch TM-1665 or ET-16 Brake Premium Non-Asbestos Material Bonded to the Brake Shoe Item 14, 2 per brake, sold each Dated 01-2024 (31LBS) H 12" L 10" W 12" Box		0	$1,698.00
11	AME-E016027	Ametek Gemco Bolt Part E016027 Old Part 24D6387G03 Brake Shoe Bolt For a 16 Inch TM-1655 & ET-16 Brake Includes Hardened Bolt Nut & Pin Item 16, 2 per brake, sold each Ships in 3 Weeks, Peck MI Dated 01-2024 (8LBS) H 4" L 8" W 4" Box	-	0	$420.00
12	AME-E019024	Ametek Gemco Brake Shoe Assembly TM 19" Part E019024 aka E019024002 aka Old Part 439C394G01 Brake Shoe & Lining Assembly For a 19 Inch TM-1985 or ET-19 Brake Premium,Non-Asbestos Lining Material Bonded to the Brake Shoe Qty. 1, 2 per brake, sold each Item 14 Normally a Stock Item @ BPI Ships from Stock to 6 Weeks Dated 01-2025 (45LBS) H 12" L 20" W 12" Box	-	0	$2,411.00
13	AME-E019027	Ametek Gemco Brake Shoe Bolt Part E019027 For a TM-1985 or ET19 Brake Shoe Item 16, 2 per brake, sold each 1.25 Inch Dia 10.5 Inch Long Threaded both ends 1 end has pin hole, Nut for use with pin, 1 pin Nut is on & pinned C. F. for Pricing Dated 01-2024 aka 24D6387G01 (5 LBS)	-	0	Call	Call
14	AME-E019065	Ametek Gemco Lining Kit 19" Part E019065 aka E019065005 Old Part 861C691G20 439C394H02 For a 19 Inch TM-1985 DC Brake Pair of Drilled & Countersunk Linings Includes 26 Rivets 10-18, 24 Required Also available undrilled for bonded brake shoes Premium Non Asbestos Material MSDS Sheets Available Ships from Stock to 3 Weeks C. F. for Pricing Dated 01-2024 (10LBS) H 10" L 18" W 10" Box		1	Call	Call
15	AME-E023025	Ametek Gemco Brake Shoe & Lining TM23 Part E023025 aka E023025999 Old Part 635C316G01 For a 23 Inch TM-2311 DC Brake Item 14, 2 per brake, sold each Premium Bonded, Non-Asbestos Material Ships in 10 to 11 Weeks, Peck MI C. F. for Pricing Dated 01-2024	-	0	Call	Call
16	AME-E023028	Ametek Gemco Brake Shoe Bolt TM-2311 Part E023028 aka E023028002 Hardened Brake Shoe Bolt For Mounting the Brake Shoes Includes Bolt Nut & Lockwasher For a 23 Inch TM-2311 DC Brake Item 16, 2 per Brake, sold each Old WEST 24D6387G02 Ships in 4 Weeks C. F. for Pricing Dated 01-2024 (12LBS) H 4" L 12" W 4" Box	-	0	Call	Call
17	AME-E030040	Ametek Gemco Bolt, Hardened Brake Shoe Bolt Assembly for a TM-3014 30 Inch Brake. Includes the Hex Nut. Ref. # 16, 2 per brake but sold individually, 450A869G01 C. F. for Pricing Dated 01-2024	-	0	Call	Call

GEMCO ET Brakes Replacement Parts

GEMCO ET8 Brakes Replacement Parts

No	Part Number	Description	Image	Stock Qty	Price Each
1	AME-E008025	Ametek Gemco Brake Shoe Assembly TM 8" Part E008025 aka E008025002 Brake Shoe & Lining Assembly For an 8 Inch TM-83 or ET-8 Brake Item 14, 2 per brake, sold each Premium Bonded, Non-Asbestos Material Old WEST 439C314G02 Normally a Stock Item @ BPI Ships from Stock to 3 Weeks Dated 01-2024 (3LBS) H 4" L 8" W 4" Box		0	$880.00
2	AME-E010070	Ametek Gemco Bolt. Brake Shoe Bolt Assembly Hardened Bolt with Nut, Lockwasher & Cotter Pin For a TM-83, TM-1035 & ET-10 Brake 2 per brake, sold each aka 27D7221H14 Dated 01-2024	-	2	$243.00
3	AME-PSD0146500	Ametek Gemco Repair Kit Thruster Part PSD0146500 Repair - Seal Kit For Thruster Assemblies: PSD0151705 PSD0148317 PSD0148305 PSD0165807 PSD0175907 Brakes: ET8, ET10 ET11 & ET11NA Item 8A Ships in 6 to 8 Weeks, Peck MI Dated 10-2021 (2LBS) H 4" L 6" W 4" Box		0	$6,419.52

GEMCO ET10 Brakes Replacement Parts

No	Part Number	Description	Image	Stock Qty	Price Each
1	AME-E010047	Ametek Gemco Brake Shoe Assembly TM 10" Part E010047 aka E0100470002 Old Part 635C292G01 For a 10 Inch TM-1035 or ET-10 Brake Item 14 2 per brake, sold each Premium OEM Non-Asbestos Bonded Lining Material Normally a Stock Item @ BPI Ships from Stock to 3 Weeks Dated 01-2024 (5LBS) H 4" L 10" W 4" Box		0	$1,060.00
2	AME-E010070	Ametek Gemco Bolt. Brake Shoe Bolt Assembly Hardened Bolt with Nut, Lockwasher & Cotter Pin For a TM-83, TM-1035 & ET-10 Brake 2 per brake, sold each aka 27D7221H14 Dated 01-2024	-	2	$243.00
3	AME-E010309	Ametek Gemco Tie Rod Assembly for an ET-10 Brake	-	1	$406.08
4	AME-E010286	Ametek Gemco Self Adjust Assembly Kit for an ET10 Brake	-	0	$1,427.76
5	AME-PSD0146500	Ametek Gemco Repair Kit Thruster Part PSD0146500 Repair - Seal Kit For Thruster Assemblies: PSD0151705 PSD0148317 PSD0148305 PSD0165807 PSD0175907 Brakes: ET8, ET10 ET11 & ET11NA Item 8A Ships in 6 to 8 Weeks, Peck MI Dated 10-2021 (2LBS) H 4" L 6" W 4" Box		0	$6,419.52
6	AME-E010266	Ametek Gemco Spring. Main Spring on a ET-10 Brake	-	0	$71.28
7	AME-E010312	Ametek Gemco Pin Kit for an ET-10 Thruster Brake. Includes Base Pins & Top Pins with Retaining Rings	-	0	$304.56

GEMCO ET13 Brakes Replacement Parts

No	Part Number	Description	Image	Stock Qty	Price Each
1	AME-E013194	Ametek Gemco Base / Frame Part E013194 For a 13 Inch ET-13 Thruster Brake Item 1, 1 per brake Dated	-	0	$2,292.84
2	AME-E013025	Ametek Gemco Brake Shoe & Lining TM13 Part E013025 aka E013025002 Old Part 439C201G01 For a 13 Inch TM1355 or ET13 Brake Item 14, 2 per brake, sold each Bonded, Premium Non-Asbestos Lining Material Normally a Stock item @ BPI Ships from Stock to 3 Weeks Dated 01-2024 (12LBS) H 8" L 12" W 8" Box	-	0	$1,275.00
3	AME-E013053	Ametek Gemco Bolt TM1355 Part E013053 aka E013053006 Old Part 24D6387G04 Hardened Brake Shoe Bolt Assembly For 13 Inch TM-1355 DC Brake Item 16, 2 per brake, sold each Normally a Stock Item @ BPI Ships from Stock to 3 Weeks Dated 01-2024 (5LBS)	-	0	$367.00
4	AME-PM0139600	Ametek Gemco Arm. Outer Shoe Arm on a ET13 Brake. 1 Pair. Item 4 4/7	-	0	$597.24
5	AME-E013228	Ametek Gemco Tie Rod Assembly Part E013228 For a 13 Inch ETH-13EB50 Thruster Brake Item 5, 1 per brake Dated	-	1	$457.92
6	AME-E013240	Ametek Gemco Tie Rod Assembly Part E013240 Self Adjust Tie Rod Assembly For a 13 Inch ET-13 Thruster Brake with the Self Adjust Option Item 5A, 1 per brake Dated	-	0	$1,469.88
7	AME-E013225	Ametek Gemco Arm Part E013225 Inner Shoe Arm For a 13 Inch ET-13 Thruster Brake Item 6 / 1 Pair Dated	-	0	$711.72
8	AME-E013229	Ametek Gemco Force Arm Assembly Part E013229 For a 13 Inch ET-13 Thruster Brake Item 7, 1 per brake Dated	-	0	$361.80
9	AME-PSD0146500	Ametek Gemco Repair Kit Thruster Part PSD0146500 Repair - Seal Kit For Thruster Assemblies: PSD0151705 PSD0148317 PSD0148305 PSD0165807 PSD0175907 Brakes: ET8, ET10 ET11 & ET11NA Item 8A Ships in 6 to 8 Weeks, Peck MI Dated 10-2021 (2LBS) H 4" L 6" W 4" Box		0	$6,419.52
10	AME-E013231	Ametek Gemco Pin Kit for a ET-13 Brake. Includes Base Pins and Top Pins with Retaining Rings. Item 10	-	0	$406.08

GEMCO ET16 Brakes Replacement Parts

No	Part Number	Description	Image	Price Each
1	AME-E016025	Ametek Gemco Brake Shoe Assembly TM 16" Part E016025 aka E016025002 Old Part 635C227G01 For a 16 Inch TM-1665 or ET-16 Brake Premium Non-Asbestos Material Bonded to the Brake Shoe Item 14, 2 per brake, sold each Dated 01-2024 (31LBS) H 12" L 10" W 12" Box		$1,698.00
2	AME-E016027	Ametek Gemco Bolt Part E016027 Old Part 24D6387G03 Brake Shoe Bolt For a 16 Inch TM-1655 & ET-16 Brake Includes Hardened Bolt Nut & Pin Item 16, 2 per brake, sold each Ships in 3 Weeks, Peck MI Dated 01-2024 (8LBS) H 4" L 8" W 4" Box	-	$420.00
3	AME-PSD0146500	Ametek Gemco Repair Kit Thruster Part PSD0146500 Repair - Seal Kit For Thruster Assemblies: PSD0151705 PSD0148317 PSD0148305 PSD0165807 PSD0175907 Brakes: ET8, ET10 ET11 & ET11NA Item 8A Ships in 6 to 8 Weeks, Peck MI Dated 10-2021 (2LBS) H 4" L 6" W 4" Box		$6,419.52

GEMCO ET19 Brakes Replacement Parts

No	Part Number	Description	Image	Price Each	Update Cart
1	AME-E019024	Ametek Gemco Brake Shoe Assembly TM 19" Part E019024 aka E019024002 aka Old Part 439C394G01 Brake Shoe & Lining Assembly For a 19 Inch TM-1985 or ET-19 Brake Premium,Non-Asbestos Lining Material Bonded to the Brake Shoe Qty. 1, 2 per brake, sold each Item 14 Normally a Stock Item @ BPI Ships from Stock to 6 Weeks Dated 01-2025 (45LBS) H 12" L 20" W 12" Box	-	$2,411.00
2	AME-E019027	Ametek Gemco Brake Shoe Bolt Part E019027 For a TM-1985 or ET19 Brake Shoe Item 16, 2 per brake, sold each 1.25 Inch Dia 10.5 Inch Long Threaded both ends 1 end has pin hole, Nut for use with pin, 1 pin Nut is on & pinned C. F. for Pricing Dated 01-2024 aka 24D6387G01 (5 LBS)	-	Call	Call
3	AME-PSD0146500	Ametek Gemco Repair Kit Thruster Part PSD0146500 Repair - Seal Kit For Thruster Assemblies: PSD0151705 PSD0148317 PSD0148305 PSD0165807 PSD0175907 Brakes: ET8, ET10 ET11 & ET11NA Item 8A Ships in 6 to 8 Weeks, Peck MI Dated 10-2021 (2LBS) H 4" L 6" W 4" Box		$6,419.52

GEMCO ET23 Brakes Replacement Parts

No	Part Number	Description	Image	Price Each	Update Cart
1	AME-E023025	Ametek Gemco Brake Shoe & Lining TM23 Part E023025 aka E023025999 Old Part 635C316G01 For a 23 Inch TM-2311 DC Brake Item 14, 2 per brake, sold each Premium Bonded, Non-Asbestos Material Ships in 10 to 11 Weeks, Peck MI C. F. for Pricing Dated 01-2024	-	Call	Call
2	AME-E023028	Ametek Gemco Brake Shoe Bolt TM-2311 Part E023028 aka E023028002 Hardened Brake Shoe Bolt For Mounting the Brake Shoes Includes Bolt Nut & Lockwasher For a 23 Inch TM-2311 DC Brake Item 16, 2 per Brake, sold each Old WEST 24D6387G02 Ships in 4 Weeks C. F. for Pricing Dated 01-2024 (12LBS) H 4" L 12" W 4" Box	-	Call	Call
3	AME-PSD0146500	Ametek Gemco Repair Kit Thruster Part PSD0146500 Repair - Seal Kit For Thruster Assemblies: PSD0151705 PSD0148317 PSD0148305 PSD0165807 PSD0175907 Brakes: ET8, ET10 ET11 & ET11NA Item 8A Ships in 6 to 8 Weeks, Peck MI Dated 10-2021 (2LBS) H 4" L 6" W 4" Box		$6,419.52

Hydraulic Brakes - Hydraulic Shoe Brakes (H Style)

DESCRIPTION

The hydraulic shoe brakes are spring released and hydraulically set for controlled stopping. Applications such as indoor and outdoor bridge cranes are just some of the examples. These proven high performance brake systems are tough, reliable and provide trouble free service. Brake wheel sizes ranging from 6 inches to 18 inches are available. Brakes are available either with standard hydraulic setting, setting with parking feature or with air powered hydraulic operation. The powered systems may be direct or remote controlled. Air remote control, hydraulic remote control, and electric remote control allow the customer the flexibility to satisfy most requirements.

Gemco Industrial Brakes stop virtually any type of industrial machine. Applications such as steel mills, indoor and outdoor bridge cranes, gantries, heavy-duty cranes, high-duty cycle cranes, lock and dam projects, stacker reclaimers, and commercial laundry equipment are just some of the uses for Gemco Industrial Brakes. These field proven high performance brake systems were originally designed and built by Westinghouse and Wagner Industrial Brakes. They are tough, reliable and provide extended, trouble free service. That's because they are designed and built to exacting specifications. For more than 40 years, Gemco has been an acknowledged leader in brake system technology for heavy-duty industrial applications.

Documentation Download:
• Industrial Brake Brochure
• Industrial Brake Systems Application Guide
• Type H and HM Installation, Dimensions and Service Manual
• Hydraulic Brakes Replacement Parts Manual
• Gemco 720D Hydraulic Brake Systems User Guide

CAD Drawings Download:
• 6 Inch Type H J023020 (PDF)
• 8 Inch Type H J002779 (PDF)
• 10 Inch Type H J002926 (PDF)
• 14 Inch Type H J002929 (PDF)
• 18 Inch Type H J002932 (PDF)
• 6 Inch Type HM J024579 (PDF)
• 8 Inch Type HM J003205 (PDF)
• 10 Inch Type HM J034780 (PDF)
• 14 Inch Type HM J034735 (PDF)
• 18 Inch Type HM J040065 (PDF)

GEMCO Hydraulic Shoe Brakes (H, HM Style)

No	Part Number	Description	Image	Stock Qty	Price Each
1	AME-J023020	Ametek Gemco Hydraulic Brake 6 Inch H Part J023020 aka J23020 J023020001 6 X 3 Inch Hydraulic Brake Assembly 150 FT LB / Manual Foot Pedal Operation 350 FT LB / Pneumatic Powered Operation Dim. 12.625 X 10.5625 Inches Ships in 8 Weeks, Peck MI Dated 01-2025 (29LBS)	-	1	$3,817.00
2	AME-J002779	Ametek Gemco Hydraulic Brake 8 Inch H Part J002779 aka J002779001 8 X 3 Inch Hydraulic Brake Assembly 200 to 450 FT LBS Includes the Actuating Cylinder Does NOT include the Brake Wheel Ships from Stock to 5 Weeks Dated 01-2025 (30LB) H 30" L 30" W 30" Box		0	$4,063.00
3	AME-J002926	Ametek Gemco Hydraulic Brake 10 Inch H Part J002926 aka J002926001 10 Inch Diameter Type "H" Hydraulic Brake Ships less the Hydraulic Actuator Which must be size selected & purchased separately 0 to 425 FT LBS on a Manual Brake System 0 to 1000 FT LBS on a Air over Hydraulic Powered Brake System A 10 X 4 Inch Brake Wheel is not included Ships from Stock to 5 weeks Dated 01-2024 Motor Freight Only (93LBS) on a wooden skid	-	0	$4,745.00
4	AME-J002929	Ametek Gemco Hydraulic Brake 14 Inch H Part J002929 aka J002929001 14 Inch Diameter Type "H" Hydraulic Brake 0 to 600 LB FT Maximum Dynamic Torque with on a Single Manual Brake System 0 to 1400 LB FT Maximum Dynamic Torque with an Air Powered Brake System Ships less the Hydraulic Actuator which must be selected & purchased separately A 14 X 6 Inch Brake Wheel is not included Motor Freight Only Ships in 8 to 10 Weeks Dated 01-2024 (161LBS) H 29" L 29" W 29" Skid		0	$6,769.00
5	AME-J002932	Ametek Gemco Hydraulic Brake, 18 Inch Type H Part J002932 18 Inch Type "H" Hydraulically Actuated Brake 0 to 900 LBS / FT of Dynamic Stopping Torque on a Manual Brake System 0 to 1800 LBS / FT of Dynamic Stopping Torque with a Air / Hydraulic Brake System 27.75 Inches Wide 34.375 Inches High with the brake being applied The Hydraulic Brake Actuator and the Brake Wheel are sold separately Ships in 10 Weeks, Peck MI Dated 01-2025 (266LBS) Motor Freight Only	-	0	$10,862.00
6	AME-J024579	Ametek Gemco Hydraulic Brake 6 Inch HM Part J024579 6 X 3 Inch Type HM Brake 150 FT LBS Manual Operation @ 70 LBS Foot Pressure 350 FT LBS Available with an Air Over Hydraulic Brake System Includes Actuator HM = Brake has Spring Set Parking & Holding @ 35 FT LBS Dated 01-2024 (30LBS)	-	0	$5,330.00
7	AME-J003205	Ametek Gemco Hydraulic Brake 8 Inch HM Part J003205 8 X 3 Inch Type HM Brake 200 FT LBS Manual Operation via 70 LBS Pedal Pressure 450 FT LBS via a Powered Air Over Hydraulic System M = Spring Set Parking & Holding @ 50 FT LBS Includes the Brake Actuator For both Service & Parking Torque 1/2-20 UNF-2B Thread Inlet Hyd for Service & Park Used with HM Parking Brake Control Unit J107206, Not Included aka J3205, J003205001 Dated 01-2024 (32LBS) H 14" L 8" W 18" Box	-	0	$5,557.00
8	AME-J034780	Ametek Gemco Hydraulic Brake 10 Inch HM Part J034780 Hydraulic Brake 10 Inch Diameter Type HM with Parking Cylinder but less the Actuator Cylinder Ships in 8 Weeks, Peck MI Dated 01-2025 (107LBS)	-	0	$8,534.00
9	AME-J034735	Ametek Gemco Hydraulic Brake 14 Inch HM Part J034735 14 X 6 Inch Type HM Hydraulic Brake With the HM Parking Cylinder Brake does not come with the Actuating Cylinder Dated 01-2024 Ships in 10 Weeks, Peck MI Motor Freight Only Dated 03-2025 (200LBS)	-	0	$13,760.00
10	AME-J040065	Ametek Gemco Hydraulic Brake 18 Inch HM Part J040065 18 X 8.5 Inch Type HM Hydraulic Brake With the HM Parking Cylinder Brake does not come with the Actuating Cylinder Ships in 5 Weeks, Peck MI Motor Freight Only Dated 01-2024 (260LBS)	-	0	$12,509.00

GEMCO Hydraulic Shoe Brakes (H, HM Style) Brake Wheels

No	Part Number	Description	Image	Stock Qty	Price Each
1	AME-J076200	Ametek Gemco Brake Wheel 6 Inch Part J076200 aka JE76200 For the J023020 & J024579 Hyd Brake Assemblies With a Solid - Center Drilled Hub D = 6.00 Inch Brake Wheel Diameter F = 3.25 Inch Brake Face Width O = 3.12 Inch Hub Offset from Centerline H = 4.00 Inch Hub Length HD = 3.00 Inch Hub Diameter Cast from ASTM A 536 Ductile Iron 80-60-03 or 80-55-06 Ships from Stock to 4 Weeks Dated 01-2023 (16LBS) H 5" L 7" W 7" Box	-	0	$1,423.00
2	AME-J076225	Ametek Gemco Brake Wheel 8 Inch Part J076225 aka JE76225 J076225002 For the AME-J002779 & J003205 Hyd Brake Assemblies With a Pilot / Stock Bore D = 8.00 Inch Brake Wheel Diameter F = 3.25 Inch Brake Face Width O = 3.12 Inch Hub Offset from Centerline H = 4.00 Inch Hub Length Through Bore 3.50 Inch Hub Diameter 4.745 Inch Overall Width Cast from ASTM A 536 Ductile Iron 80-60-03 or 80-55-06 Ships in 1 Week Dated 1/18 (26LBS) H 5" L 8" W 8" Box	-	0	$1,108.08
3	AME-J076227	Ametek Gemco Hydraulic Brake Wheel 8 Inch Diameter 3.25 Inch Face Width 3.12 Inch Hub Offset 2.00 Inch Hub Bore 3.50 Inch Hub Length 0.50 X 0.25 Inch Keyway Hub Length Bore & Keyway for 603, 604, 803 & 804 Mill Motors aka JE76227 [Amazon] Dated 1/18 (26LBS) H 7" L 8" W 8" Box	-	1	$1,564.92
4	AME-J076228	Ametek Gemco Hydraulic Brake Wheel Part AME-J076228 Hub Length Bore & Keyway for: 602 802 AC1 AC2 & AC4 Motors D = 8 Inch Diameter F = 3.25 Inch Face Width O = 3.12 Inch Hub Offset B = 1.75 Inch Hub Bore 3.00 Inch Hub Length 0.50 X 0.25 Inch Keyway Dated 1/18 (26LBS) H 7" L 8" W 8" Box	-	1	$1,564.92
5	AME-J076250	Ametek Gemco Brake Wheel 10 Inch Part J076250 aka J076250002 JE76250 With a Solid / Stock Bore, Center Drilled D = 10.00 Inch Brake Wheel Diameter F = 4.25 Inch Brake Face Width O = 3.12 Inch Hub Offset from Centerline H = 5.50 Inch Hub Length Through Bore 5.00 Inch Hub Diameter Cast from ASTM A 536 Ductile Iron 80-55-06 For the AME-J002926, AME-J034789 & AME-J053958 Brake Assemblies Ships in 6 Weeks, Peck MI Dated 01-2023 (55LBS) H 6" L 10" W 10" Box	-	0	$2,289.00
6	AME-J076251	Ametek Gemco Hydraulic Brake Wheel Part AME-J076251 10 Inches In Diameter 4.25 Inch Face Width 3.12 Inch Offset 2.50 Inch Bore Diameter 4.00 Inch Hub Length 0.50 X 0.250 Inch Keyway Hub Length, Bore & Keyway for a 606 & 806, AC8 & AC12 Mill Motors aka JE76251 [Amazon] Date 1/18 (55LBS) H 6" L 10" W 10" Box	-	1	$2,323.08
7	AME-J076252	Ametek Gemco Hydraulic Brake Wheel Part AME-J076252 10 Inches In Diameter 4.25 Inch Face Width 3.12 Inch Offset 2 Inch Bore Diameter 3.5 Inch Hub Length 0.50 X 0.250 Inch Keyway Hub Length, Bore & Keyway for a 603, 604, 803 & 804 Mill Motors aka JE76252 [Amazon] Dated 1/18 (55LBS) H 6" L 10" W 10" Box	-	1	$2,323.08
8	AME-J076253	Ametek Gemco Hydraulic Brake Wheel Part AME-J076253 10 Inches In Diameter 4.25 Inch Face Width 3.12 Inch Offset 3.00 Inch Bore Diameter 4.50 Inch Hub Length 0.75 X 0.250 Inch Keyway Hub Length, Bore & Keyway for a 608 & 808 Mill Motors aka JE76253 [Amazon] Dated 1/18 (55LBS) H 6" L 10" W 10" Box	-	1	$2,323.08
9	AME-J076254	Ametek Gemco Hydraulic Brake Wheel Part AME-J076254 10 Inches In Diameter 4.25 Inch Face Width 3.12 Inch Offset 3.25 Inch Bore Diameter 4.50 Inch Hub Length 0.75 X 0.250 Inch Keyway Hub Length, Bore & Keyway for a 610, 810 & AC18 Mill Motors aka JE76254 [Amazon] Dated 1/18 (55LBS) H 6" L 10" W 10" Box	-	1	$2,323.08
10	AME-J076255	Ametek Gemco Hydraulic Brake Wheel Part AME-J076255 10 Inches In Diameter 4.25 Inch Face Width 3.12 Inch Offset 3.625 Inch Bore Diameter 5.00 Inch Hub Length 0.75 X 0.250 Inch Keyway Hub Length, Bore & Keyway for a 612, 812, AC25 & AC30 Mill Motors aka JE76255 Dated 1/18 (55LBS) H 6" L 10" W 10" Box	-	1	$2,323.08
11	AME-J076256	Ametek Gemco Hydraulic Brake Wheel Part AME-J076256 10 Inches In Diameter 4.25 Inch Face Width 3.12 Inch Offset 1.75 Inch Bore Diameter 3.00 Inch Hub Length 0.50 X 0.25 Inch Keyway Hub Length Bore & Keyway for 602, 802, AC1, AC2 & AC4 Mill Motors aka JE76256 [Amazon] Dated 1/18 (55LBS) H 6" L 10" W 10" Box	-	1	$2,323.08
12	AME-J076275	Ametek Gemco Brake Wheel 14 Inch J0 Part J076275 aka J076275002 With a Pilot / Stock Bore D = 14.00 Inch Brake Wheel Diameter F = 6.50 Inch Brake Face Width O = 4.25 Inch Hub Offset from Centerline H = 5.50 Inch Hub Length Through Bore 5.00 Inch Hub Diameter Solid Hub with Bore Center Drilled For the AME-J002929, AME-J0347345 & AME-J053957 Brake Assemblies Cast from ASTM A 536 Ductile Iron 80-60-03 or 80-55-06 Dated 1--2021 (121LBS) H 8" L 14" W 14" Box	-	0	$4,248.72
13	AME-J076276	Ametek Gemco Brake Wheel 14 Inch Part J076276 For the AME-J002929, AME-J0347345 & AME-J053957 Brake Assemblies 14.00 Inch Brake Wheel Diameter 6.50 Inch Brake Face Width 4.25 Inch Hub Offset from Centerline 5.00 Inch Hub Length Through Bore 5.75 Inch Hub Diameter 3.625 Inch Hub Bore Diameter 0.75 X 0.25 Keyway Hub Length Bore & Keyway for 612, 812, AC25 & AC30 Mill Motors Cast from ASTM A 536 Ductile Iron 80-60-03 or 80-55-06 aka JE76276 [Amazon] Dated 1/18 (121LBS) H 8" L 14" W 14" Box	-	1	$3,646.08
14	AME-J076277	Ametek Gemco Brake Wheel 14 Inch Part J076277 For the AME-J002929, AME-J0347345 & AME-J053957 Brake Assemblies 14.00 Inch Brake Wheel Diameter 6.50 Inch Brake Face Width 4.25 Inch Hub Offset from Centerline 4.50 Inch Hub Length Through Bore 5.75 Inch Hub Diameter 3.00 Inch Hub Bore Diameter 0.75 X 0.25 Keyway Hub Length Bore & Keyway for 608, 808 Mill Motors Cast from ASTM A 536 Ductile Iron 80-60-03 or 80-55-06 aka JE76277 Dated 1/18 (121LBS) H 8" L 14" W 14" Box	-	1	$3,646.08
15	AME-J076278	Ametek Gemco Brake Wheel 14 Inch Part J076278 For the J002929, J0347345 & J053957 Brake Assemblies 14.00 Inch Brake Wheel Diameter 6.50 Inch Brake Face Width 4.25 Inch Hub Offset from Centerline 4.00 Inch Hub Length Through Bore 5.75 Inch Hub Diameter 2.50 Inch Hub Bore Diameter 0.50 X 0.25 Keyway Hub Length Bore & Keyway for 606, 806, AC8 & AC12 Mill Motors Cast from ASTM A536 Ductile Iron 80-60-03 or 80-55-06 aka JE76278 Dated 7/18 (121LBS) H 8" L 14" W 14" Box	-	0	$3,943.08
16	AME-J076279	Ametek Gemco Brake Wheel 14 Inch Part J076279 For the AME-J002929, AME-J0347345 & AME-J053957 Brake Assemblies 14.00 Inch Brake Wheel Diameter 6.50 Inch Brake Face Width 4.25 Inch Hub Offset from Centerline 4.50 Inch Hub Length Through Bore 5.75 Inch Hub Diameter 3.25 Inch Hub Bore Diameter 0.75 X 0.25 Keyway Hub Length Bore & Keyway for 610, 810 & AC18 Mill Motors Cast from ASTM A536 Ductile Iron 80-60-03 or 80-55-06 aka JE76279 Dated 1/18 (121LBS) H 8" L 14" W 14" Box	-	0	$3,646.08
17	AME-J076300	Ametek Gemco Brake Wheel 18 Inch Part J076300 aka JE76300 For the J002932, J040065 & J058855 Brake Assemblies With a Stock / Pilot Bore 1 Inch D = 18.00 Inch Brake Wheel Diameter F = 8.50 Inch Brake Face Width O = 5.25 Inch Hub Offset from Centerline H = 6.38 Inch Hub Length Through Bore 7.50 Inch Hub Diameter Cast from ASTM A 536 Ductile Iron 80-60-03 or 80-55-06 Box on a Skid Motor Freight Only Dated 10-2021 (230LBS) H 10" L 18" W 18"	-	1	$9,705.96
18	AME-J076301	Ametek Gemco Hydraulic Brake Wheel Part AME-J076301 18 Inch Diameter 8.50 Inch Face Width 5.25 Inch Hub Offset 3.625 Inch Hub Bore 5.00 Inch Hub Length 0.75 X 0.250 Inch Keyway Hub Length Bore & Keyway for 612, 812, AC25 & AC30 Mill Motors aka JE76301, BH181005 Dated 1/18 (230 LBS) Motor Freight Only	-	0	$7,842.96
19	AME-J076302	Ametek Gemco Hydraulic Brake Wheel Part AME-J076302 18 Inch Diameter 8.50 Inch Face Width 5.25 Inch Hub Offset 4.25 Inch Hub Bore 5.00 Inch Hub Length 1.00 X 0.375 Inch Keyway Hub Length Bore & Keyway for 614, 814, AC40 & AC50 Mill Motors aka JE76302 Dated 1/18 (230 LBS) Motor Freight Only	-	0	$7,842.96
20	AME-J076303	Ametek Gemco Hydraulic Brake Wheel Part AME-J076303 18 Inch Diameter 8.50 Inch Face Width 4.88 Inch Hub Offset 3.25 Inch Hub Bore 4.50 Inch Hub Length 0.75 X 0.250 Inch Keyway Hub Length Bore & Keyway for 610, 810 & AC18 Mill Motors aka JE76303 (230 LBS) Motor Freight Only	-	0	$7,842.96
21	AME-J076304	Ametek Gemco Hydraulic Brake Wheel Part AME-J076304 18 Inch Diameter 8.50 Inch Face Width 5.25 Inch Hub Offset 4.62 Inch Hub Bore 5.50 Inch Hub Length 1.25 X 0.375 Inch Keyway Hub Length Bore & Keyway for 616 & 816 Mill Motors aka JE76304 Dated 1/18 (230 LBS) Motor Freight Only	-	0	$7,842.96
22	AME-J076305	Ametek Gemco Hydraulic Brake Wheel Part AME-J076305 18 Inch Diameter 8.50 Inch Face Width 5.25 Inch Hub Offset 5.00 Inch Hub Bore 6.00 Inch Hub Length 1.25 X 0.50 Inch Keyway Hub Length Bore & Keyway for 618 & 818 Mill Motors aka JE76305 Dated 1/18 (230LBS) Motor Freight Only	-	0	$7,842.96
23	AME-J076306	Ametek Gemco Hydraulic Brake Wheel Part AME-J076306 18 Inch Diameter 8.50 Inch Face Width 4.88 Inch Hub Offset 3.00 Inch Hub Bore 4.50 Inch Hub Length 0.75 X 0.250 Inch Keyway Hub Length Bore & Keyway for 608 & 808 Mill Motors aka JE76306 Dated 1/18 (230LBS) Motor Freight Only	-	0	$7,842.96
24	AME-J076322	Ametek Gemco Hydraulic Brake Wheel Part AME-J076322 18 Inch Diameter 8.50 Inch Face Width 5.25 Inch Hub Offset 3.25 Inch Hub Bore 4.50 Inch Hub Length 0.75 X 0.250 Inch Keyway Hub Length Bore & Keyway for 610, 810 & AC18 Mill Motors aka JE76322 Dated 1/18 (230LBS) Motor Freight Only	-	0	$7,842.96
25	AME-J076323	Ametek Gemco Hydraulic Brake Wheel Part AME-J076323 18 Inch Diameter 8.50 Inch Face Width 5.25 Inch Hub Offset 2.50 Inch Hub Bore 4.00 Inch Hub Length 0.50 X 0.250 Inch Keyway Hub Length Bore & Keyway for 606, 806, AC8 & AC12 Mill Motors aka JE76323 230 LBS Motor Freight Only	-	0	$7,773.53
26	AME-J076324	Ametek Gemco Hydraulic Brake Wheel Part AME-J076324 18 Inch Diameter 8.50 Inch Face Width 5.25 Inch Hub Offset 3.00 Inch Hub Bore 4.50 Inch Hub Length 0.75 X 0.250 Inch Keyway Hub Length Bore & Keyway for 608 & 808 Mill Motors aka JE76324 Dated 1/18 (230LBS) Motor Freight Only	-	0	$7,773.53

GEMCO Hydraulic Shoe Brakes Brake Shoes, Linings, Bolts and Pins

No	Part Number	Description	Image	Stock Qty	Price Each
1	AME-J001235	Ametek Gemco - Wagner Brake Shoe Assembly Part J001235 aka J001235XXX 14 Inch Hydraulic Brake Shoe & Lining Newer Style Pin & Snap Rings which are included Premium Bonded Non-Asbestos Lining Material Item 25, 2 per brake, sold each Casting # 1225 aka J1235 Normally a Stock Item @ BPI Ships from Stock to 4 Weeks Dated 01-2024 (23LBS) H 6" L 16" W 8" Box		0	$1,487.00
2	AME-J001803	Ametek Gemco / Wagner Brake Shoe Assembly Part J001803 18 Inch Hydraulic Brake Shoe & Lining Newer Style, Includes New Pin & Snap Rings Premium Bonded Non-Asbestos Lining Material Item 25, 2 per brake, sold each Casting 1799 aka J1803 JF1803 Stock to 5 Weeks Dated 01-2024 (35LBS) H 8" L 14" W 8" Box	-	2	$1,850.00
3	AME-J006110	Ametek Gemco Brake Shoe Assembly H 10" Part J006110 aka J006110XXX 10 Inch Hydraulic Brake Shoe & Lining With Newer Style Pin & Snap Rings which are included For Brakes J002926 & J34780 Premium Bonded Non-Asbestos Lining Material Item 26, 2 per brake, sold each Casting # JFD6108 Ships from Stock to 3 Weeks Dated 01-2024 (9LBS) H 5" L 10" W 5" Box		1	$1,117.00
4	AME-J006874	Ametek Gemco Pin Part J006874 For an 18 Inch Brake Assembly 4 per Brake, sold each 2 for Brake Shoes 2 for Brake Shoe Arms Older style that uses a nut & lockwasher 6.5 Inches Long, 1.25 Inch Diameter 1-14 Threads, 1.25 Thread Length Dated (1LB)	-	369	$29.16
5	AME-J006942	Ametek Gemco Pin Part J006942 For a 10 Inch Hyd Brake Brake Shoe & Brake Arm Pin 4 per brake, sold each 4.875 Inch Long 0.75 Inch Diameter 9/16 - 18 Thread (1LB) M00034717	-	24	$28.08
6	AME-J007844	Ametek Gemco Brake Shoe Assembly Part J007844 aka J007844002 Brake Shoe & Lining Complete with Bushings For J002779 or J003205 8 Inch Hydraulic Brakes Item 2, 2 per brake, sold each Normally a Stock Item @ BPI Ships from Stock to 3 Weeks Dated 01-2024 (7LBS) H 4" L 10" W 5" Box		2	$806.00
7	AME-J023021	Ametek Gemco Brake Shoe Assembly 6" Part J023021 aka J023021002 J23021 Brake Shoe, Lining & Pin Bushing For J023020 or J024579 6 Inch Hydraulic Brakes Item 2, 2 per brake, sold each Normally a Stock Item @ BPI Ships from Stock to 3 Weeks Dated 06-2022 (6LBS) H 4" L 10" W 5" Box	-	0	$649.00
8	AME-J023024	Ametek Gemco Lining 6" Part J023024 aka J023024002 J23024 For a 6 x 3 Inch Hydraulic Brake Assembly With 6, Drilled and Countersunk Holes 2 per brake, 1 per brake shoe, sold each Requires J000387 Brass Fasteners which are not included Undrilled for bonded applications are also available Non Asbestos Premium RF38 Material MSDS Sheet Available Ships from Stock to 10 Days Dated 01-2024 (1LB) H 4" L 5" W 4" Box	-	0	$116.00
9	AME-J073930	Ametek Gemco Pin Kit Part J073930 aka J073930005 New Style for the 18 Inch Brake as of June 1992 1 Pin complete with Snap Rings & Grease Fitting Item 8 Largest Pin on the brake 4 per brake, sold each Bottom of Brake Shoe Arms & Brake Shoe Mounting Pin 5.94 Inches Long 1.25 Inch Diameter Replaces Old J006874 or J073936 which is still available as J073936 Ships from Stock to 3 Weeks Dated 01-2024 (1LB)	-	1	$114.00
10	AME-J073931	Ametek Gemco Old Pin Kit Part J073931 10 Inch Brake Shoe Pin with Nut, Lockwasher & Grease Fitting Dated 01-2024	-	0	$103.00
11	AME-J073936	Ametek Gemco Old Pin Kit Part J073936 Pre June 1992 1 Pin on an 18 Inch Brake Assembly 4 per Brake 2 for the Brake Shoes & 2 for Brake Shoe Arm Bottoms Older Style that comes complete with a Nut, Lockwasher & Grease Fitting 6.5 Inches Long 1.25 Inch Diameter 1-14 Threads 1.25 Thread Length & Interference Serration Old J006874 Dated 01-2024 (3LBS) H 4" L 5" W 4" Box		5	$114.00
12	AME-J105194	Ametek Gemco Friction Plug Kit Part J105194 For a 10 Inch Hydraulic Brake Part J002926 & J003205 Items 6 & 7 Qty 2 J006528 Spring Qty 2 J006942 Pin Holds Brake Shoes in position Dated 01-2024 (1LB) H 4" L 4" W 4" Box		3	$160.00
13	AME-J105196	Ametek Gemco Friction Plug Kit Part J105196 For a 18 Inch Hydraulic Brake Assembly Holds brake shoes in the released position Items 6 & 7 Two J006528 Springs & Two J006876 Plugs Dated 01-2024 (1LB) H 4" L 5" W 4" Box		3	$164.00
14	AME-PSD01495	Ametek Gemco Brake Shoe. Brake Shoe Assembly with Bonded Lining. 11 Inch for ET-11NA Brake	-	0	$548.64

Ametek Gemco Hydraulic Shoe Brakes (H, HM Style) Replacement Parts

Magnetic Brakes - Magnetic DC Shoe Brakes (TM Style)

DESCRIPTION

The magnetic DC shoe brakes are spring set and electrically released. The brake is set when 230 VDC power is removed from the brakes coil(s). The type TM brakes electrical mechanism consists of one or two DC magnets. As power is introduced to the coils it creates an electro-magnetic field that brings the coils together to release the brake. Cutting power to the coils allows the spring to extend back to its normal state and sets the brake. Shunt or series coils are available and rated for continuous or intermittent duty ratings. We also offer single point adjustment on brakes 8 inches in wheel diameter or larger. This speeds up the brake installation and shoe lining wear adjustment by a single point adjusting feature. Brake wheel diameters of 4 1/2" to 30" are available, and are AISE rated. Rectifiers are available for AC operation.

Gemco Industrial Brakes stop virtually any type of industrial machine. Applications such as steel mills, indoor and outdoor bridge cranes, gantries, heavy-duty cranes, high-duty cycle cranes, lock and dam projects, stacker reclaimers, and commercial laundry equipment are just some of the uses for Gemco Industrial Brakes. These field proven high performance brake systems were originally designed and built by Westinghouse and Wagner Industrial Brakes. They are tough, reliable and provide extended, trouble free service. That's because they are designed and built to exacting specifications. For more than 40 years, Gemco has been an acknowledged leader in brake system technology for heavy-duty industrial applications.

Documentation Download:
• Industrial Brake Brochure
• Industrial Brake Systems Application Guide
• Models CB and TM Magnetic Shoe Brakes Manual

CAD Drawings Download
• TM43 (PDF)
• TM63 (PDF)
• TM83 (PDF)
• TM83 (ZIP, DWG)
• TM1035 (PDF)
• TM1355 (PDF)
• TM1655 (PDF)
• TM1985 (PDF)
• TM2311 (PDF)
• TMSC8 (PDF)
• TMSC10 (PDF)
• TMSC13 (PDF)
• TMSC16 (PDF)
• TMSCH10 (PDF)

GEMCO TM AIST DC Brakes

No	Part Number	Description	Image	Stock Qty	Price Each
1	AME-TM-1035	Ametek Gemco DC Brake 10 " Part TM-1035 TM1035 Heavy Duty AIST Spring Set Magnetically Released Brake Assembly Direct Current Clapper Type 10 Inch Wheel Diameter Voltage DC with Shunt or Series Wound Coils With Series Coils 200 FT. LBS., 1/2 Hour & 130 FT LBS 1 Hour With Shunt Coils 200 FT. LBS., 1 Hour & 150 FT LBS 8 Hours A 10 X 3.75 Inch Brake Wheel is not included A Rectifier for AC Voltages is available at additional cost Motor Freight Only Normally a Stock Item with a Shunt Wound Coil Normally a Stock Item @ BPI Ships from Stock to 8 Weeks Dated 01-2025 (165LBS)	-	0	$9,492.00
2	AME-TM-1355	Ametek Gemco DC Brake 13 Inch Part TM-1355 TM1355 Heavy Duty 13 Inch DC Magnetic Brake Assembly Manufactured to AIST Specifications Direct Current Clapper Type 13 Inch Wheel Diameter Voltage DC With Shunt or Series Wound Coils Shunt Coils 550 FT. LBS. 1 Hour & 400 Ft Lbs 8 Hours Series Coils 550 FT. LBS. 1/2 Hour & 365 FT Lbs. 1 Hour Options available at additional cost Include: 13 Inch Brake Wheel with a Pilot or Finished Bore & Keyway Secondary Operation via a Hydraulic Slave Cylinder For progressive brake application from a crane cab A Rectifier for AC to DC Conversion - Operation Manual Hand Release Lever Set or Release Switches to confirm brake status Ships via Motor Freight Only Ships in 10 Weeks, Peck MI Dated 01-2024 (330LBS) Gross H 16" L 26" W 36" Skid		0	$12,438.00
3	AME-TM-1665	Ametek Gemco DC Brake 16 Inch Part TM-1665 TM1665 Heavy Duty AIST Spring Set Magnetic Release Shoe Brake Assembly Direct Current Clapper Type 16 Inch Wheel Diameter, Voltage DC with Shunt or Series Wound Coils With Series Coils 1000 Ft. Lbs. 1/2 Hour & 650 Ft Lbs. 1 Hour With Shunt Coils 1000 Ft. Lbs. 1 Hour & 750 Ft Lbs 8 Hours Coil Part must be identified at time of order. A 16 X 6.75 Inch Brake Wheel is NOT included Rectifier for AC Voltages are available at additional cost Mfg in Peck MI Ships in 14 to 16 Weeks, Peck MI Dated 05-2024	-	0	$18,458.00
4	AME-TM-1985	Ametek Gemco Heavy Duty DC Brake Model TM-1985 aka TM1985 AIST Spring Set Magnetically Released, Shoe Brake Assembly Direct Current Clapper Type Steel Mill Brake For AIST Class D, E & F Overhead Cranes Voltage DC with Shunt or Series Wound Coils, Class "B" Insulation With Series Coils 2000 FT LBS 1/2 Hour & 1300 FT LBS 1 Hour With Shunt Coils 2000 FT LBS 1 Hour & 1500 Ft Lbs 8 Hours A Magnet / Shoe Travel Indicator to facilitates brake adjustment Twin-magnet coils are Epoxy-encapsulated for permanent protection against dust, water, grease, oil, chemicals and mechanical impact Coils can be replaced while the brake continues to set / under load Self Aligning Cast Iron Brake Shoes with Bonded Linings for maximum lining wear Premium Non-Asbestos High Temperature Brake Lining Material Options available at additional cost include: A Brake Wheel / Pulley, with a Pilot Bore or with a Finished, Hub Length Bore & Keyway Rectifiers for AC Voltages, with Enclosure or an Open Chassis Design for mounting in your panel Brake Enclosures, Designed to meet NEMA 4 or NEMA 3R ratings A Hand Release Lever, Resistors Part E019000001 With Shunt Wound Coils Ships in 12 Weeks, Peck MI Dated 1-19 Motor Freight Only Brake Weight 870 LBS Net Dated 01-2024 (900LBS) H 26" L 42" W 30" Skid / Box	-	0	$40,030.00
5	AME-TM-43	Ametek Gemco DC Brake Assembly TM Part TM-43 TM43 DC Magnetic Brake Assembly, Mfg to AIST Standards Heavy Duty Spring Set, Magnetic Release Shoe Brake Assembly Direct Current Clapper Type Brake 4.5 Inch Diameter Provided with a Shunt Wound Coil Part E004051 Designed for 1 or 8 Hour Duty Cycle 80 Volts Intermittent 64 Volts Continuous 25 Ft LBS @ 1 Hour 15 FT LBS @ 8 Hours Options Available some at additional cost include: A Brake Wheel 4.500 X 3.125 / Finished or Pilot Bore Part E004500 Series Wound Coil, same cost AC to DC Rectifiers, Part E010326 with NEMA 4 Enclosure or Part E010326 Open Chassis Design A Manual Hand Release Lever, latching or non-latching NEMA 3 and 4 Brake Enclosures Normally a Stock Item @ BPI with Shunt Wound Coil Ships from Stock to 8 Weeks Dated 01-2024 (41LBS) H 15" L 20" W 10" Box		0	$3,369.00
6	AME-TM-63	Ametek Gemco DC Brake Assembly 6" TM Model TM-63 TM63 DC Magnetic Brake Assembly, Meets the AIST Standards Heavy Duty Spring Set, Magnetic Release Shoe Brake Assembly Direct Current Clapper Type Brake 6.00 Inch Diameter Provided with a Shunt Wound Coil E006026 Designed for 1 or 8 Hour Duty Cycle 80 Volts Intermittent 64 Volts Continuous 50 FT LBS @ 1 Hour 40 FT LBS @ 8 Hours Options Available some at additional cost include: A Brake Wheel 6.00 X 3.125 / Finished or Pilot Bore Series Wound Coil, same cost AC to DC Rectifiers Part E010326 with NEMA 4 Enclosure Part E010326 Open Chassis Design A Manual Hand Release Lever, latching or non-latching NEMA 3 and 4 Brake Enclosures Normally a Stock Item @ BPI Ships from Stock to 8 Weeks Dated 01-2024		1	$3,544.00
7	AME-TM-83	Ametek Gemco DC Brake Assembly 8 Inch Part TM-83 TM83 Heavy Duty AIST Spring Set Magnetic Release Shoe Brake Assembly Direct Current Clapper Type 8 Inch Wheel Diameter Voltage DC with Shunt or Series Wound Coils With Shunt Coils 100 Ft. Lbs. 1 Hour & 75 Ft Lbs 8 Hours With Series Coils 100 Ft. Lbs. 1/2 Hour & 65 Ft Lbs. 1 Hour An 8 X 3.25 Inch Brake Wheel is not included Rectifier for AC Voltages is available at additional cost Normally a Stock item with Shunt Wound Coils Ships from Stock to 8 Weeks Dated 01-2025 (100LBS)	-	1	$8,618.00

GEMCO TMSC AIST DC Brakes

No	Part Number	Description	Image	Stock Qty	Price Each
1	AME-TMSC-1035	Ametek Gemco DC Brake Part TMSC-1035 Heavy Duty AIST Spring Set Magnetic Release Shoe Brake Assembly Direct Current Clapper Type 10 Inch Wheel Diameter With Shunt Wound Coils 200 FT. LBS. 1 Hour & 150 FT LBS 8 Hours Ships in 8 to 10 Weeks Motor Freight Only Dated 01-2025 (165LBS) H 18" L 20" W 32" Skid		0	$9,492.00
2	AME-TMSC-1355	Ametek Gemco Brake 13 Inch DC Part TM-1355 aka TM1355 Heavy Duty AISE Spring Set Magnetic Release Shoe Brake Assembly Direct Current Clapper Type 13 Inch Wheel Diameter Voltage DC With Shunt or Series Wound Coils Series Coils 550 FT LBS 1/2 Hour & 365 FT LBS 1 Hour Shunt Coils 550 FT LBS 1 Hour & 400 FT LBS 8 Hours The TMSC Brake has interlocking shoe arms that allow single point adjustment for lining wear Brake Weight 290 LBS Gross 350 Motor Freight Only Ships in 8 Weeks, Peck MI Dated 1-2020 (200 LBS) H 36" L 36" W 36"	-	0	$13,433.04
3	AME-TMSC-1665	Ametek Gemco DC Magnetic Brake Assembly Part TMSC-1665 aka TMSC1655 Heavy Duty AIST Spring Set Magnetic Release Shoe Brake Assembly Direct Current Clapper Type Mfg to AIST Standards 16 Inch Wheel Diameter Voltage DC with Shunt or Series Wound Coils With Series Coils 1000 Ft. Lbs. 1/2 Hour & 650 Ft Lbs. 1 Hour With Shunt Coils 1000 Ft. Lbs. 1 Hour & 750 Ft Lbs 8 Hours The TMSC Brake has interlocking shoe arms that allow for a single point adjustment for lining wear (520LBS) Shipping Weight A 16 X 6.75 Inch Brake Wheel is NOT included Rectifier for AC Voltages are available at additional cost Ships in 8 Weeks, Peck MI, Motor Freight Only Dated 1-2020 (520LBS) H 24" L 32" W 20" Skid		1	$15,186.96
4	AME-TMSC-83	Ametek Gemco AIST 8 Inch DC Brake Part TMSC-83 TMSC83 Heavy Duty Spring Set Magnetically Released Brake Assembly Direct Current Clapper Type 8 Inch Wheel Diameter Voltage DC with Shunt or Series Wound Coils With Series Coils 100 FT LB 1/2 Hour & 65 FT LB 1 Hour With Shunt Coils 100 FT LB 1 Hour & 75 FT LB 8 Hours A 8 X 3.25 Inch Brake Wheel is not included Rectifier for AC Voltages is available at additional cost Ships in 8 Weeks, Peck MI Dated 06-2022 (110LBS) H 10" L 30" W 20"		1	$7,168.00
5	AME-TMSCH-1355	Ametek Gemco Electric / Hydraulic Brake Part TMSCH-1355 13 Inch Diameter DC Electric Brake Type TMSC With a Hydraulic Actuating Cylinder Brake Assembly Only This Brake is Spring Set and Electrically Released When electrically released the Hydraulic Actuator becomes usable via a hydraulic brake system which is not included Voltage DC with Shunt Coils 550 Ft LBS 1 Hour & 400 FT LBS 8 Hours Hydraulic Operation 550 FT LBS Maximum Brake Weight 290 LBS. plus skid A Brake Wheel is not included Ships from stock to 6 weeks Dated 7/18		1	$13,767.84
6	AME-TMSCH-1355 SYSTEM	Ametek Gemco Electric / Hydraulic Brake System Part TMSCH-1355 System 13 Inch Diameter DC Electric Brake type TMSC with a Hydraulic Actuating Cylinder This Brake is Spring Set and Electrically Released, when electrically released the Hydraulic Actuator becomes usable by the hydraulic foot pedal System to include the Brake TMSC-1355 Fluid Reservoir / Bleeder Bleeder Pushbutton Switch J01008 Control Cylinder J017616 with Pedal J008219 4 Armored Hose Kits J010797 Hydraulic Tubing by 100 Feet Hydraulic Fittings, Gaskets, Brackets & Wagner Super Heavy Duty Brake Fluid Voltage DC with Shunt Wound Coils 550 Ft LBS 1 Hour & 400 FT LBS 8 Hours 550 Ft LBS via Hydraulic Operation Brake Weight 260 LBS., plus system components & shipping skid A Brake Wheel is not included Ships in 6 weeks, Peck MI Dated 7/18	-	0	$20,041.56
7	AME-TMSCH-1665	Ametek Gemco Electric / Hydraulic Brake 16 Inch Diameter DC Electric Brake Type TMSC Part TMSCH-1665 With a Hydraulic Actuating Cylinder Brake Assembly Only This Brake is Spring Set and Electrically Released When electrically released the Hydraulic Actuator becomes usable via a hydraulic brake system which is not included Voltage DC with Shunt Coils 1000 Ft LBS 1 Hour & 750 FT LBS 8 Hours Brake Weight 500 LBS. plus skid A Brake Wheel is not included Ships in 6 weeks, Peck MI Dated 7/18	-	0	$18,437.76
8	AME-TMSCH-83	Ametek Gemco Electric / Hydraulic Brake 8 Inch Diameter DC Electric Brake Type TMSC Part TMSCH-83 aka TMSCH83 With a Hydraulic Actuating Cylinder Brake Assembly Only This Brake is Spring Set and Electrically Released When electrically released the Hydraulic Actuator becomes usable via a hydraulic brake system which is not included Voltage DC with Shunt Coils 100 Ft LBS 1 Hour & 75 FT LBS 8 Hours Brake Weight 155 LBS. plus skid A Brake Wheel is not included Ships in 8 weeks, Peck MI Dated 1-2020	-	0	$9,645.48
9	AME-TMSCH-83 SYSTEM	Ametek Gemco Electric / Hydraulic Brake System Part TMSCH-83 System 8 Inch Diameter DC Electric Brake type TMSC with a Hydraulic Actuating Cylinder This Brake is Spring Set and Electrically Released, when electrically released the Hydraulic Actuator becomes usable by the hydraulic foot pedal System to include the Brake TMSC-83 Fluid Reservoir / Bleeder Bleeder Pushbutton Switch J01008 Control Cylinder J017616 with Pedal J008219 4 Armored Hose Kits J010797 Hydraulic Tubing by 100 Feet Hydraulic Fittings, Gaskets, Brackets & Wagner Super Heavy Duty Brake Fluid Voltage DC with Shunt Wound Coils 100 Ft LBS 1 Hour & 75 FT LBS 8 Hours Brake Weight XX LBS., plus system components & shipping skid A Brake Wheel is not included Ships in 6 weeks, Peck MI Dated 7/18	-	0	$15,366.24

GEMCO TM AIST DC Brakes Brake Wheels

No	Part Number	Description	Image	Stock Qty	Price Each
1	AME-E004500	Ametek Gemco Brake Wheel 4.5 Inch Part E004500 aka E004500999 For the TM-43 DC Brake Assembly With the Offset Style Hub 4.50 Inch Wheel Diameter 3.13 Inch Face Width 2.62 Inch Hub Offset 2.00 Inch Hub Length Through Bore 2.75 Inch Hub Diameter Solid Hub with Bore Center Drilled 1.625 Inch Maximum Recommended Bore 9850 Maximum RPM Cast from ASTM A 536 Ductile Iron 80-60-03 or 80-55-06 Normally a Stock Item @ BPI Ships from Stock to 4 Weeks Dated 01-2025 (6LBS) H 5" L 5" W 5" Box		4	$1,501.00
2	AME-E004600	Ametek Gemco Brake Wheel 4.5 Inch	-	0	$1,234.44
3	AME-E006500	Ametek Gemco Brake Wheel 6 Inch Part E006500 aka E006500999 Old Part 834D992H15 For the TM-63 DC Brake Assembly And ET-6NA Thruster Brake With the Offset Style Hub, Stock Bore 6.00 Inch Brake Wheel Diameter 3.13 Inch Face Width 3.00 Inch Hub Offset 3.50 Inch Hub Length Through Bore 3.25 Inch Hub Diameter Solid Hub with Bore Center Drilled 2.00 Inch Maximum Recommended Bore 7375 Maximum RPM Cast from ASTM A 536 Ductile Iron 80-60-03 or 80-55-06 Dated 01-2024 (16LBS) H 5" L 6" W 6" Box		10	$1,508.00
4	AME-E008500	Ametek Gemco Brake Wheel 8 Inch TM Part E008500 aka E008500999 For the TM-83 DC Brake Assembly And ET-8 Thruster Brake With the Offset Style Hub, Stock Bore 8.02 Inch Brake Wheel Diameter 3.25 Inch Face Width 3.00 Inch Hub Offset 3.50 Inch Hub Length Through Bore 3.25 Inch Hub Diameter Solid Hub with Bore Center Drilled 2.25 Inch Maximum Recommended Bore 5525 Maximum RPM Cast from ASTM A 536 Ductile Iron 80-60-03 or 80-55-06 Dated 10-2021	-	1	$1,523.88
5	AME-E008501	Ametek Gemco Brake Wheel. 8 Inch Diameter Brake Wheel with a Finished Bore and Keyway for a 603, 604, 803 & 804 Mill Motor	-	0	$1,564.92
6	AME-E008514	Ametek Gemco Brake Wheel. 8 Inch Diameter Brake Wheel with a Finished Bore and Keyway for a 402, 602 0r 802 Mill Motor	-	0	$1,405.08
7	AME-E008515	Ametek Gemco Brake Wheel. 8 Inch Diameter,3.25 Face Width, 4.25 Inch Offset, 1.875 Bore with a 1/2 X 1/4 Keyway	-	0	$1,405.08
8	AME-E010500	Ametek Gemco Brake Wheel 10 Inch Part E010500 aka E010500999 For the TM-1035 DC Brake Assembly And ET-10 Thruster Brake With the Offset Style Hub, Stock Bore 10.02 Inch Brake Wheel Diameter 3.75 Inch Face Width 4.25 Inch Hub Offset 4.25 Inch Hub Length Through Bore 3.75 Inch Hub Diameter Solid Hub with Bore Center Drilled 2.75 Inch Maximum Recommended Bore 4425 Maximum RPM Cast from ASTM A 536 Ductile Iron 80-60-03 or 80-55-06 Ships in 4 Weeks, Peck MI Dated 10-2021 (40LBS) H 6" L 10" W 10" Box	-	0	$2,179.44
9	AME-E010535	Ametek Gemco Brake Wheel. 10 Inch Diameter Brake Wheel with a Finished Bore and Keyway for a 606 & 806 Mill Motor Dated 1/18	-	0	$2,323.08
10	AME-E013500	Ametek Gemco Brake Wheel 13 Inch TM Part E013500 aka E0135000999 For the TM-1355 & ET-13 Brakes With the Offset Style Hub And a Pilot Bore 13.02 Inch Brake Wheel Diameter 5.75 Inch Face Width 4.25 Inch Hub Offset 5.38 Inch Hub Length Through Bore 5.75 Inch Hub Diameter Solid Hub with Bore Center Drilled 3.75 Inch Maximum Recommended Bore 3400 Maximum RPM Cast from ASTM A 536 Ductile Iron 80-60-03 or 80-55-06 Dated 10-2021 Ships in 4 weeks, Peck MI (95LBS) H 9" L 13" W 13" Box	-	1	$3,477.60
11	AME-E013513	Ametek Gemco Brake Wheel Part E013513 13 Inch Diameter with a Hub Length Bore & Keyway for an 808 Mill Motor With the AIST Standard Offset Ships in 4 weeks, Peck MI Dated 1/18 (95LBS) H 9" L 13" W 13" Box	-	0	$3,110.40
12	AME-E013520	Ametek Gemco Brake Wheel Part E013520 13 Inch Diameter with a hub length bore & keyway for a 612 & 812 Mill Motor With the AIST Standard Offset Dated 1/18 UPS able Ships in 4 weeks, Peck MI	-	0	$3,110.40
13	AME-E013543	Ametek Gemco Brake Wheel Part E013543 13 Inch Diameter Brake Wheel With a Hub Length Bore & Keyway for: 603 604 803 & 804 Mill Motors Dated 1/18 Ships in 4 weeks, Peck MI	-	0	$3,110.40
14	AME-E013544	Ametek Gemco Brake Wheel Part E013544 13 Inch Diameter Brake Wheel With a Hub Length Bore & Keyway for: 606 & 806 Mill Motors Dated 1/18 Ships in 4 weeks, Peck MI	-	0	$3,110.40
15	AME-E016500	Ametek Gemco Brake Wheel 16 Inch TM Part E016500 aka E0016500999 For the TM-1655 DC Brake Assembly And ET-16 Thruster Brake With the Offset Style Hub, Stock Bore 16.02 Inch Brake Wheel Diameter 6.75 Inch Face Width 6.50 Inch Hub Offset 5.50 Inch Hub Length Through Bore 7.00 Inch Hub Diameter Solid Hub with Bore Center Drilled 4.50 Inch Maximum Recommended Bore 2750 Maximum RPM Cast from ASTM A 536 Ductile Iron 80-60-03 or 80-55-06 Old WEST 7937A40H01 Motor Freight Only Ship in 4 Weeks Dated 10-2021 (150LBS) H 10" L 16" W 16" Box on Skid	-	1	$5,428.08
16	AME-E016506	Ametek Gemco Brake Wheel 16 Inch Diameter with a hub length bore & keyway for a 612 & 812 Mill Motor with the AISE Standard Offset	-	0	$4,481.99
17	AME-E016513	Ametek Gemco Brake Wheel 16 Inch Diameter with a hub length bore & keyway for a 606 & 806 Mill Motor with the AISE Standard Offset	-	0	$4,481.99
18	AME-E016526	Ametek Gemco Brake Wheel 16 Inch Diameter with a hub length bore & keyway for a 608 & 808 Mill Motor with the AISE Standard Offset	-	0	$4,481.99
19	AME-E016528	Ametek Gemco Brake Wheel 16 Inch Diameter with a hub length bore & keyway for a 614 & 814 Mill Motor with the AISE Standard Offset	-	0	$4,481.99
20	AME-E016538	Ametek Gemco Brake Wheel 16 Inch Part E016538 With a Finished Bore & Keyway Ships in 4 Weeks, Peck MI Dated 1-19	-	0	$5,401.08
21	AME-E019500	Ametek Gemco Brake Wheel 19 Inch For the TM-1955 DC Brake Assembly And ET-19 Thruster Brake With the Offset Style Hub, Stock Bore 19.02 Inch Brake Wheel Diameter 8.75 Inch Face Width 7.50 Inch Hub Offset 6.00 Inch Hub Length Through Bore 7.00 Inch Hub Diameter Solid Hub with Bore Center Drilled 4.625 Inch Maximum Recommended Bore 2350 Maximum RPM Cast from ASTM A 536 Ductile Iron 80-60-03 or 80-55-06 Part AME-E019500 (250LBS) H 12" L 19" W 19" Box on Skid, Motor Freight Only [Amazon]	-	1	$5,406.05
22	AME-E023500	Ametek Gemco Brake Wheel 23 Inch For the TM-2375 DC Brake Assembly With the Offset Style Hub, Stock Bore 23.02 Inch Brake Wheel Diameter 11.25 Inch Brake Face Width 8.75 Inch Hub Offset from Centerline 7.31 Inch Hub Length Through Bore 8.50 Inch Hub Diameter Solid Hub with Bore Center Drilled 5.50 Inch Maximum Recommended Bore 1925 Maximum RPM Cast from ASTM A 536 Ductile Iron 80-60-03 or 80-55-06 Part AME-E023500 (450LBS) H 12" L 23" W 23" Box on Skid, Motor Freight Only [Amazon]	-	1	$9,256.41
23	AME-E030500	Ametek Gemco Brake Wheel 30 Inch For the TM-3014 DC Brake Assembly With the Offset Style Hub, Stock Bore 30.04 Inch Brake Wheel Diameter 14.25 Inch Brake Face Width 10.75 Inch Hub Offset from Centerline 9.25 Inch Hub Length Through Bore 13.00 Inch Hub Diameter Solid Hub with Bore Center Drilled 7.50 Inch Maximum Recommended Bore 1475 Maximum RPM Cast from ASTM A 536 Ductile Iron 80-60-03 or 80-55-06 Part AME-E030500 (850LBS) H 19" L 30" W 30" Box on Skid, Motor Freight Only [Amazon]	-	1	$15,427.34

GEMCO TM AIST DC Brake Shoes, Linings, Bolts and Pins

No	Part Number	Description	Image	Stock Qty	Price Each	Update Cart
1	AME-E004047	Ametek Gemco Brake Shoe Assembly TM-43 Part E004047 aka 645C555G02 E004047002 Brake Shoe & Lining For a TM-43 4.5 Inch Electric Brake Bonded Premium Non-Asbestos Lining Material 2 Per brake, sold each 70 Degree Arc Dated 01-2024 (2LBS) H 4" L 5" W 4" Box	-	4	$749.00
2	AME-E004070	Ametek Gemco Bolt Part E004070 Hardened Brake Shoe Bolt For a TM-43 or TM-63 DC Brake aka 27D7221H04 E004070006 Item 15, 2 per brake, sold each Dated 01-2024 (1LB)	-	0	$237.00
3	AME-E006023	Ametek Gemco Brake Shoe Assembly TM 6" Part E006023 aka E006023002 For 6 Inch a TM-63, ET6 or ET6NA Brake Bonded Premium Non-Asbestos Lining Material Sold each, 2 per Brake 70 Degree Arc Old Part 645C162G02 & 645C162J04 Casting # Normally a Stock Item @ BPI Ships from Stock to 4 weeks Dated 01-2024 (2LBS) H 4" L 10" W 4" Box		0	$806.00
4	AME-E008025	Ametek Gemco Brake Shoe Assembly TM 8" Part E008025 aka E008025002 Brake Shoe & Lining Assembly For an 8 Inch TM-83 or ET-8 Brake Item 14, 2 per brake, sold each Premium Bonded, Non-Asbestos Material Old WEST 439C314G02 Normally a Stock Item @ BPI Ships from Stock to 3 Weeks Dated 01-2024 (3LBS) H 4" L 8" W 4" Box		0	$880.00
5	AME-E010047	Ametek Gemco Brake Shoe Assembly TM 10" Part E010047 aka E0100470002 Old Part 635C292G01 For a 10 Inch TM-1035 or ET-10 Brake Item 14 2 per brake, sold each Premium OEM Non-Asbestos Bonded Lining Material Normally a Stock Item @ BPI Ships from Stock to 3 Weeks Dated 01-2024 (5LBS) H 4" L 10" W 4" Box		0	$1,060.00
6	AME-E010107	Ametek Gemco Shoe & Lining CB 10" Part E010107 aka E010107006 Old Part 254C27G04 Outer Brake Shoe For a CB-160 10 Inch Electric Brake Bonded Premium Non-Asbestos Lining Material Normally a Stock Item @ BPI Ships from Stock to 3 Weeks Dated 01-2025 (15LBS)		0	$1,988.00
7	AME-E010108	Ametek Gemco Lining & Rivet Kit CB160 Part E010108 aka E010108005 Old Part 3279B95G04 For a 10 Inch CB-160 Solenoid Brake Premium OEM Non-Asbestos Drilled Linings Qty. 2, with 6 Drilled and Countersunk Holes & 18 Brass Push Pins Linings for 2 Brake Shoes - 1 Pair Normally a Stock Item at BPI Ships from our Stock to 2 Weeks C. F. for Pricing Dated 01-2024 (2LBS) H 4" L 8" W 4" Box	-	5	$2,529.80
8	AME-E013025	Ametek Gemco Brake Shoe & Lining TM13 Part E013025 aka E013025002 Old Part 439C201G01 For a 13 Inch TM1355 or ET13 Brake Item 14, 2 per brake, sold each Bonded, Premium Non-Asbestos Lining Material Normally a Stock item @ BPI Ships from Stock to 3 Weeks Dated 01-2024 (12LBS) H 8" L 12" W 8" Box	-	0	$1,275.00
9	AME-E013053	Ametek Gemco Bolt TM1355 Part E013053 aka E013053006 Old Part 24D6387G04 Hardened Brake Shoe Bolt Assembly For 13 Inch TM-1355 DC Brake Item 16, 2 per brake, sold each Normally a Stock Item @ BPI Ships from Stock to 3 Weeks Dated 01-2024 (5LBS)	-	0	$367.00
10	AME-E016025	Ametek Gemco Brake Shoe Assembly TM 16" Part E016025 aka E016025002 Old Part 635C227G01 For a 16 Inch TM-1665 or ET-16 Brake Premium Non-Asbestos Material Bonded to the Brake Shoe Item 14, 2 per brake, sold each Dated 01-2024 (31LBS) H 12" L 10" W 12" Box		0	$1,698.00
11	AME-E016027	Ametek Gemco Bolt Part E016027 Old Part 24D6387G03 Brake Shoe Bolt For a 16 Inch TM-1655 & ET-16 Brake Includes Hardened Bolt Nut & Pin Item 16, 2 per brake, sold each Ships in 3 Weeks, Peck MI Dated 01-2024 (8LBS) H 4" L 8" W 4" Box	-	0	$420.00
12	AME-E019024	Ametek Gemco Brake Shoe Assembly TM 19" Part E019024 aka E019024002 aka Old Part 439C394G01 Brake Shoe & Lining Assembly For a 19 Inch TM-1985 or ET-19 Brake Premium,Non-Asbestos Lining Material Bonded to the Brake Shoe Qty. 1, 2 per brake, sold each Item 14 Normally a Stock Item @ BPI Ships from Stock to 6 Weeks Dated 01-2025 (45LBS) H 12" L 20" W 12" Box	-	0	$2,411.00
13	AME-E019027	Ametek Gemco Brake Shoe Bolt Part E019027 For a TM-1985 or ET19 Brake Shoe Item 16, 2 per brake, sold each 1.25 Inch Dia 10.5 Inch Long Threaded both ends 1 end has pin hole, Nut for use with pin, 1 pin Nut is on & pinned C. F. for Pricing Dated 01-2024 aka 24D6387G01 (5 LBS)	-	0	Call	Call
14	AME-E019065	Ametek Gemco Lining Kit 19" Part E019065 aka E019065005 Old Part 861C691G20 439C394H02 For a 19 Inch TM-1985 DC Brake Pair of Drilled & Countersunk Linings Includes 26 Rivets 10-18, 24 Required Also available undrilled for bonded brake shoes Premium Non Asbestos Material MSDS Sheets Available Ships from Stock to 3 Weeks C. F. for Pricing Dated 01-2024 (10LBS) H 10" L 18" W 10" Box		1	Call	Call
15	AME-E023025	Ametek Gemco Brake Shoe & Lining TM23 Part E023025 aka E023025999 Old Part 635C316G01 For a 23 Inch TM-2311 DC Brake Item 14, 2 per brake, sold each Premium Bonded, Non-Asbestos Material Ships in 10 to 11 Weeks, Peck MI C. F. for Pricing Dated 01-2024	-	0	Call	Call
16	AME-E023028	Ametek Gemco Brake Shoe Bolt TM-2311 Part E023028 aka E023028002 Hardened Brake Shoe Bolt For Mounting the Brake Shoes Includes Bolt Nut & Lockwasher For a 23 Inch TM-2311 DC Brake Item 16, 2 per Brake, sold each Old WEST 24D6387G02 Ships in 4 Weeks C. F. for Pricing Dated 01-2024 (12LBS) H 4" L 12" W 4" Box	-	0	Call	Call
17	AME-E030040	Ametek Gemco Bolt, Hardened Brake Shoe Bolt Assembly for a TM-3014 30 Inch Brake. Includes the Hex Nut. Ref. # 16, 2 per brake but sold individually, 450A869G01 C. F. for Pricing Dated 01-2024	-	0	Call	Call

Ametek Gemco Magnetic DC Shoe Brakes (TM Style) Replacement Parts

Ametek Gemco Solenoid DC Shoe Brakes (TM Style Brakes, DC Heavy Duty AISE Spring Set Magnetic Release Shoe Brakes):

• TM43 Brake Assembly & Parts
• TM63 Brake Assembly & Parts
• TM83 Brake Assembly & Parts
• TM1035 Brake Assembly & Parts
• TM1355 Brake Assembly & Parts
• TM1655 Brake Assembly & Parts
• TM1985 Brake Assembly & Parts
• TM2311 Brake Assembly & Parts
• TM3014 Brake Assembly & Parts

Solenoid Brakes - Solenoid AC Shoe Brakes (CB Style)

DESCRIPTION

The solenoid AC shoe brakes are spring set and electrically released. The brake is set when power is removed from the brake solenoid assembly. Solenoid assemblies can be powered by 115 VAC thru 575 VAC, single phase. Brake wheel diameters ranging from 4 1/2 inches to 10 inches are available.

Gemco Industrial Brakes stop virtually any type of industrial machine. Applications such as steel mills, indoor and outdoor bridge cranes, gantries, heavy-duty cranes, high-duty cycle cranes, lock and dam projects, stacker reclaimers, and commercial laundry equipment are just some of the uses for Gemco Industrial Brakes. These field proven high performance brake systems were originally designed and built by Westinghouse and Wagner Industrial Brakes. They are tough, reliable and provide extended, trouble free service. That's because they are designed and built to exacting specifications. For more than 40 years, Gemco has been an acknowledged leader in brake system technology for heavy-duty industrial applications.

Documentation Download:
• Industrial Brake Brochure
• Industrial Brake Systems Application Guide
• Models CB and TM Magnetic Shoe Brakes Manual

CAD Drawings Download:
• CB15 (PDF)
• CB35 (PDF)
• CB75 (PDF)
• CB110 (PDF)
• CB160 (PDF)

GEMCO CB AC Solenoid Brakes

No	Part Number	Description	Stock Qty	Price Each
1	AME-CB-15	Ametek Gemco Solenoid Brake Assembly Part CB-15 CB15 Spring Set / Solenoid Released 4.5 Inch Diameter Many AC Voltages 460, 230, 115, 575 60 Hz Single Phase 15 FT LB Intermittent Duty Cycle 10 Ft LB Continuous Duty Cycle Reliable design with very few parts Simple one point torque adjustment Rugged long life solenoid - tested in more than 2 million operational cycles Manual brake release with hand pressure on the solenoid arm Solenoid plunger travel indicator A mark on the plunger indicates when the brake should be adjusted for lining wear Simple two-point adjustment for lining wear Light Duty Solenoid brake for up to Class "C" Cranes Application Safety Factors need to be followed during selection Brake Wheel sold separately Normally a Stock Item @ BPI Ships from Stock to 6 Weeks Dated 01-2025 (20LBS) H 9" L 12" W 6" Box	6	$1,273.00
2	AME-CB-35	Ametek Gemco Solenoid Brake Assembly Part CB-35 CB35 Spring Set / Solenoid Released 5.50 Inch Diameter Many AC Voltages 460, 230, 115, 575 60 Hz Single Phase 35 FT LB with a Intermittent Duty Cycle 20 FT LB with a Continuous Duty Cycle Less a 5.50 X 3.25 Inch Brake Wheel E005500 Reliable design with very few parts Simple one point torque adjustment Rugged long life solenoid - tested in more than 2 million operational cycles Manual brake release with hand pressure on the solenoid arm Solenoid plunger travel indicator Simple two-point adjustment for lining wear Is a Light Duty Solenoid Brake for up to Class "C" Cranes Application Safety Factors need to be followed during selection of a brake Normally a Stock Item @ BPI Stock to 6 Weeks to Ship Dated 01-2025 (34LBS) H 12" L 18" W 14" Box	17	$1,655.00
3	AME-CB-75	Ametek Gemco Solenoid Brake Assembly Part CB-75 Spring Set / Solenoid Released 7.00 Inch Diameter Many AC Voltages 460, 230, 115, 575 60 Hz Single Phase 75 FT LB with a Intermittent Duty Cycle 50 FT LB with a Continuous Duty Cycle Less a 7.00 X 3.25 Inch Brake Wheel E007500 Options include, 230, 115 & 575 Volt Reliable design with very few parts Simple one point torque adjustment Rugged long life solenoid Tested in more than 2 million operational cycles without electrical failure Manual brake release with hand pressure on the solenoid arm Solenoid plunger travel indicator A mark on the plunger indicates when the brake should be adjusted for lining wear Simple two-point adjustment for lining wear Light Duty Solenoid Brake for up to Class "C" Cranes Application Safety Factors need to be followed during selection of a brake Normally a Stock Item @ BPI Ships from Stock to 6 Weeks to Ship Dated 01-2025 (60LBS) H 12" L 20" W 8"	0	$2,536.00
4	AME-CB-110	Ametek Gemco Solenoid Brake Assembly CB Part CB-110 CB110 Spring Set / Solenoid Released 7.00 Inch Diameter 110 - 230 - 460 - 575 Volt AC 60 Hz Single Phase 110 FT LB with a Intermittent Duty Cycle 85 FT LB with a Continuous Duty Cycle Less a 7.00 X 3.25 Inch Brake Wheel E007500 Options include, 230, 115 & 575 Volt Reliable design with very few parts Simple one point torque adjustment Rugged long life solenoid Tested in more than 2 million operational cycles without electrical failure Manual Brake Release with hand pressure on the solenoid arm Solenoid Plunger Travel Indicator Simple Two-Point adjustment for lining wear Light Duty Solenoid Brake for up to Class "C" Cranes Application Safety Factors need to be followed during selection of a brake Normally a Stock Item @ BPI Stock to 6 Weeks to Ship Dated 01-2025 (60LBS) H 12" L 20" W 7" Box	0	$4,686.00
5	AME-CB-160	Ametek Gemco Solenoid Brake Assembly Part CB-160 Spring Set / Solenoid Released 10 Inch Diameter Many AC Voltages 460, 230, 115, 575 60 Hz Single Phase 160 FT LB Intermittent Duty 125 FT LB Continuous Duty Less a 10.00 X 4.25 Inch Brake Wheel Reliable design with very few parts Simple one point torque adjustment Rugged Long Life Solenoid Tested in more than 2 million operational cycles without electrical failure Manual Brake Release with hand pressure on the solenoid arm Solenoid plunger travel indicator A mark on the plunger indicates when the brake should be adjusted for lining wear Simple two-point adjustment for lining wear Options available at additional cost include: A Brake Wheel, Pilot or Finished Bore, Pilot Bore Part E010800 Brake Enclosures NEMA 3 & 4 Light Duty Solenoid Brake for up to Class "C" Cranes Application Safety Factors need to be followed during selection of a brake Normally a Stock Item @ BPI Ships from Stock to 6 Weeks Dated 01-2025 (80LBS) H 16" L 22" W 8" Box	2	$9,394.69

GEMCO CB AC Solenoid Brakes Brake Wheels

No	Part Number	Description	Image	Stock Qty	Price Each
1	AME-E004800	Ametek Gemco Brake Wheel 4.5 Inch Part E004800 Old Part aka 2247C13H01 For the CB-15 AC Brake Assembly 4.50 Inch Brake Wheel Diameter, Stock Bore 2.75 Inch Face Width 2.64 Inch Hub Offset, when measured from centerline of face 2.20 Inch Hub Length Through Bore 2.75 Inch Hub Diameter Solid Hub with Bore Center Drilled 1.625 Inch Maximum Recommended Bore 9850 Maximum RPM Cast from ASTM A 536 Ductile Iron 80-60-03 or 80-55-06 Normally a Stock Item @ BPI Ships from Stock to 3 Weeks Dated 10-2021 (6LBS) H 5" L 5" W 5" Box	-	4	$1,272.24
2	AME-E005500	Ametek Gemco Brake Wheel 5.5 Inch Part E005500 aka E005500999 Old Part 2247C15H01 For the CB-35 AC Brake Assembly 5.50 Inch Brake Wheel Diameter, Stock Bore 3.25 Inch Face Width 2.62 Inch Hub Offset 2.62 Inch Hub Length Through Bore 2.75 Inch Hub Diameter Solid Hub with Bore Center Drilled 1.625 Inch Maximum Recommended Bore 8050 Maximum RPM Cast from ASTM A 536 Ductile Iron 80-60-03 or 80-55-06 Ships from Stock to 3 Weeks Dated 10-2021 (10LBS) H 6" L 6" W 6" Box	-	12	$1,685.88
3	AME-E007500	Ametek Gemco Brake Wheel 7 Inch Part E007500 aka E007500999 For the CB-75 & CB-110 AC Brake 7.00 Inch Brake Wheel Diameter, Stock Bore 4.25 Inch Face Width 3.26 Inch Hub Offset 2.62 Inch Hub Length Through Bore 3.13 Inch Hub Diameter Solid Hub with Bore Center Drilled 1.875 Inch Maximum Recommended Bore Cast from ASTM A 536 Ductile Iron 80-60-03 or 80-55-06 Dated 01-2025 (25LBS) H 7" L 7" W 7" Box	-	1	$1,513.00
4	AME-E007530	Ametek Gemco Brake Wheel 7 Inch 7.00 Inch Brake Wheel Diameter, Stock Bore For the CB-75 & CB-110 AC Brake With a Finished Bore & Keyway 6325 Maximum RPM Cast from ASTM A 536 Ductile Iron 80-60-03 or 80-55-06 Part AME-E007530 (25LBS) H 7" L 7" W 7" Box [Amazon]	-	0	$1,402.80
5	AME-E010800	Ametek Gemco Brake Wheel 10 Inch Part E010800 aka E010800999 For the CB-160 AC Brake Assembly 10.00 Inch Brake Wheel Diameter, Stock Bore 4.25 Inch Face Width 4.26 Inch Hub Offset 3.38 Inch Hub Length Through Bore 3.75 Inch Hub Diameter Solid Hub with Bore Center Drilled 2.25 Inch Maximum Recommended Bore 4425 Maximum RPM Cast from ASTM A 536 Ductile Iron 80-60-03 or 80-55-06 Ship in 4 Weeks, Peck MI Dated 10-2021 (40LBS) H 10" L 10" W 10" Box		0	$2,179.44
6	AME-E010807	Ametek Gemco Brake Wheel 10 Inch For the CB-160 AC Brake Assembly 10.00 Inch Brake Wheel Diameter 4.25 Inch Face Width With a Finished Bore & Keyway 4425 Maximum RPM Cast from ASTM A 536 Ductile Iron 80-60-03 or 80-55-06 Part AME-E010807 (40LBS) H 10" L 10" W 10" Box [Amazon]	-	0	$2,168.47

GEMCO CB AC Brake Shoes, Linings, Bolts and Pins

No	Part Number	Description	Image	Stock Qty	Price Each	Update Cart
1	AME-E004054	Ametek Gemco Pin Part E004054 For a CB-35 Brake Item 14, 3 per brake At the@ bottom & top of brake shoes aka 2247C08H01 E004054006 Dated 01-2024 (1LB)		1	$82.00
2	AME-E004101	Ametek Gemco Lining and Rivet Kit Part E004101 For a 4.5 Inch CB-15 AC Solenoid Brake Linings have 4 countersunk holes for the rivets Also available undrilled for bonded brake shoes 1 kit per brake A recommended spare part Old 3279B95G01 aka E004101005 C.F. for Pricing Dated 01-2024 (1LB)	-	2	Call	Call
3	AME-E004111	Ametek Gemco Spring Plate Assembly Part E004111 Spring Plate Assembly on the Tie Rod For a 4.5 Inch CB-15 AC Solenoid Brake Item 12, 1 per brake Old 3279B90G01 aka E004111999 Dated 01-2024 (2LBS) H 4" L 5" W 4" Box	-	0	$121.00
4	AME-E004113	Ametek Gemco Brake Shoe Assembly CB-15 Part E004113 aka E004113004 Inner Brake Shoe For a CB-15 Solenoid Brake 4.5 Inch With Premium OEM Non-Asbestos Lining Material Old 2254C28G01 Normally a stock item @ BPI Ships from stock to 3 Weeks Dated 01-2024 (3LBS) H 4" L 6" W 4" Box	-	0	$391.00
5	AME-E004114	Ametek Gemco Brake Shoe Assembly CB-15 Part E004114 aka E004114004 Outer Brake Shoe on a CB-15 Brake With premium non-asbestos lining material Old WEST 2254C27G01 Normally a stock item @ BPI Ships from stock to 3 Weeks Dated 01-2024 (3LBS) H 4" L 6" W 4" Box		0	$391.00
6	AME-E005027	Ametek Gemco Pin Part E005027 For a 5.5 Inch CB-35 AC Brake Item 14, 3 per brake Located at the Top & Bottom of the Brake Shoes aka 2247C08H04 Dated 01-2024 (1LB) H 4" L 5" W 4" Box	-	5	$72.00
7	AME-E005047	Ametek Gemco Brake Shoe & Lining CB35 5.5 Part E005047 aka E005047004 Old Part 2254C27G02 For a CB35 Brake Assembly Outer Shoe, away from the solenoid Bonded, Premium, Non-Asbestos Lining Material Normally a Stock Item @ BPI Ships from Stock to 3 Weeks Dated 01-2024 (5LBS) H 5" L 10" W 5" Box		6	$507.00
8	AME-E005048	Ametek Gemco Brake Shoe & Lining CB 5.5" Part E005048 aka E005048004 Old Part 247C28G02 For a CB35 Brake Assembly Inner Shoe, close to solenoid Bonded, Premium Non-Asbestos Lining Material Normally a Stock Item @ BPI Ships from Stock to 3 Weeks Dated 01-2024 (5LBS) H 5" L 10" W 5" Box	-	7	$507.00
9	AME-E007073	Ametek Gemco Brake Shoe & Lining CB 7" Part E007073 aka E007073004 Old Part 2254C27G03 For a 7 Inch CB-75 or CB-110 Brake Outer Shoe Bonded Premium OEM Non-Asbestos Lining 1 per brake Dated 01-2025 (9LBS) H 5" L 7" W 5" Box		1	$749.00
10	AME-E007074	Ametek Gemco Brake Shoe & Lining CB 7" Part E007074 aka E007074004 Old Part 2254C28G03 For a 7 Inch CB-75 or CB-110 Brake Inner Shoe Bonded Premium OEM Non-Asbestos Lining 1 per brake Dated 01-2025 (9LBS) H 5" L 7" W 5" Box	-	5	$749.00
11	AME-E010054	Ametek Gemco Pin CB-160 Part E010054 aka E010054006 For a 10 Inch CB-160 AC Brake Item 14, 3 per brake, sold each Located at the top & bottom of the brake shoes Old WEST 2247C08H10 Ships in 2 Weeks Dated 01-2024 (1LB) H 4" L 5" W 4" Box	-	0	$156.00
12	AME-E010070	Ametek Gemco Bolt. Brake Shoe Bolt Assembly Hardened Bolt with Nut, Lockwasher & Cotter Pin For a TM-83, TM-1035 & ET-10 Brake 2 per brake, sold each aka 27D7221H14 Dated 01-2024	-	2	$243.00
13	AME-E010106	Ametek Gemco Shoe & Lining CB 10" Part E010106 aka E010106006 Old Part 2254C28G04 Inner Brake Shoe For a CB-160 10 Inch Electric Brake Bonded Premium Non-Asbestos Lining Material Normally a Stock Item @ BPI Ships from Stock to 3 Weeks Dated 01-2025 (15LBS)	-	0	$1,988.00

Ametek Gemco Solenoid AC Shoe Brakes (CB Style) Replacement Parts

Ametek Gemco Solenoid AC Shoe Brakes (CB Style Brakes, AC Magnetic Shoe Brakes):

• CB15 Brake Assembly & Parts
• CB35 Brake Assembly & Parts
• CB75 Brake Assembly & Parts
• CB110 Brake Assembly & Parts
• CB160 Brake Assembly & Parts

Secure Online Order

Secure Online Order

14,389 part numbers available for
online order

Shopping Cart

Empty

Checkout is secure

Products Available From Stock
Free shipping via UPS Ground (continental US only, motor freight excluded)

Web Site Features

Part Number Lookup

Enter at least three characters of a Gemco part number to retrive the list of all documents (such as specifications, manuals, guides, drawings, etc.) from our web site, referencing this part number:

Formal PDF Quotation
To obtain an instant formal printable PDF quotation use shopping cart and select "View PDF Quote", instead of checking out. Click here for instructions.

Your shopping cart is kept intact and you can still check out at a later time.

Application Notes

Application Notes

Check-out application notes compiled using real-life situations our clients have efficiently resolved using various Gemco products, in these application areas:

• Cranes
• Battery Manufacturing
• Fiberglass Winders
• Hydraulic Cylinders
• Crusher/Baler
• Stretch Hooding Machine
• Electric Arc Furnace Cover
• And more

PLS, PLC and Network Modules

PLS, PLC and Network Modules

• 1746 LDT Interface Card
• 1989 Quik-Set III Multi-Turn PLS
• 1990DN DeviceNet Resolver
Interface Module
• 1991 Quik-Set IV UHS PLS
• 1992 Press Set
• 1995A/B/E/L Micro-Set PLS
• 1996 Ram Set
• 2110 Shut Height Monitor
• 2120 PLC Interface Module
• 2500 High Speed PLS

Rotary Feedback

Rotary Limit Switches, Position Sensors, Resolvers, Encoders

• 1950 Precision Snap Switches
• 1970 Drive-Chek Control
• 1980 Rotating Cam Limit Switch
• 1980R Rotating Cam Limit
   Switch with Resolver
• 1983 Optical Limit Switch
• 1986A standard foot mount
• 1986B 2.25" sqr flange mount
• 1986C 2.06" sqr flange mount
• 1986D 2.50" dia face mount
• 1986DN DeviceNet resolver
• 1986E 100mm face mount
• 1986G square flange mount
• 1986GG multi-turn dual
• 1986I 4.00" round face mount
• 1986F standard block style
• 1986H servo mount resolver
• 1986MD mill duty housing
• 1986XP explosion proof
• 1997 Gate Hoist Rotating Cam
   Limit Switch, Designed to
   Meet Specifications of The
   Corps of Engineers
• 2000 RLS
• 2006 RLS
• 3001 Adjustable Couplings

Linear Feedback

Linear Displacement Transducers

• 925 Linear Cable Reel Sensor
• 950IS Intrinsically Safe LDT
• 950MD Mill Duty Housing LDT
• 952 BlueOx LDT
• 953A/D/SSI VMAX LDT
• 953N ReadyLink EtherNet/IP
  LDT with RapidRecall
• 955 eBrik
• 955A BRIK Gen III LDT
• 955C/CA/CD/CDQ BRIK Gen III
• 955D BRIK Gen III LDT
• 955DQ BRIK Gen III LDT
• 955LC BRIK LDT
• 955S Smart BRIK LDT
• 955 BRIK Accessories
• 956 BLOK Housing Option
• 956S BLOK LDT
• 957N ReadyLink EtherNet/IP
  LDT with RapidRecall
• 957A, D & SSI Brik LDT
• 957A/D/SSI BRIK LDT
  Accessories
• Rod Style LDT Accessories
• LDT Magnets, Cables,
  Accessories and Parts
• 958A Embedded LDT

Other Measurements

Other Measurements

• 6012/6013 Electrode
Holders/Electrodes
• 7010 Tilt Switch Float
• 7014 Unifloat
• 7100 Leak Detect Stik
• 7230 HT Digital Probe
• 7250 Digital Stik
• 7330 Pro-Stik II

Press Safety Products

Press Safety Products

• 1999 Semelex II Safetimeter
• 1025 Foot and Palm Switches

Gemco Industrial Brakes

Gemco Industrial Brakes

• Electro-Thrust Brakes (ET)
   - Thrust Shoe Brakes
• Hydraulic Brakes (H, HM)
   - Hydraulic Shoe Brakes
   - Replacement Parts
• Magnetic Brakes (TM)
   - Magnetic DC Shoe Brakes
   - Replacement Parts
• Solenoid Brakes (CB)
   - Solenoid AC Shoe Brakes
• MSDS
   - MSDS Information

Control Relays

Control Relays

• 1500 Induction Style Relay
• 5200 Solid State Relay
• 5400 Plug In Style Solid State
Relay
• 5600 Solid State Relay
• 8040 Standard Control and
Alarm Panel
• Motogard - Over-Temperature
Protection

Frequently Requested Quotations

Frequently Requested Quotations

• Actuating Cylinder
• Hydraulic Shoe Brakes
• Solenoid DC Shoe Brakes
• Solenoid AC Shoe Brakes
• Various Replacement Parts
• 1950 Series Snap Switches
• And more

This web site is owned and operated by Brake Products, Inc.
			16751 Hilltop Park Place Chagrin Falls, Ohio 44023 Phone: (440) 543-7962 Fax: (440) 543-7963 Web: www.brakeproducts.com Email: sales@brakeproducts.com Federal ID #: 34-1473351 CAGE Code: 1QTP8 DUNS# 14-748-2392 Download: Form W-9 ACH Form: Word / PDF
Supplier of Industrial Brake Parts Since 1985 This web site: Owned and operated by Brake Products, Inc. Designed and maintaned by Internet and Database Software, Inc.
